Help CenterWhite Concrete Mixer Truck YTZ5257GJB42E
Related Products
-
Yellow Tow Truck YTZ5197TQZ40ENNegotiableMOQ: 1 Set -
Yellow Tow Truck YTZ5257TQZ40ENNegotiableMOQ: 1 Set
-
Used Tow TruckNegotiableMOQ: 1 Set
-
YUTONG Efficient 8 Cubic Meters Mixer Truck For SaleUS$ 40,000 - 950,000MOQ: 1 Piece
-
Professional And Efficient Concrete Mixer Truck For Sale With Preferential PriceUS$ 40,000 - 950,000MOQ: 1 Piece
1. Reliable quality and high operational stability
Tank body is assembled and connected by using specialized fixtures to ensure the correct concentricity of the tank body and stable operation of mixing tank.
2. High strength, durable, and long service life
The tank body and main structure are made of low alloy steel with high strength and great wear resistance.
It has dual sealing head structure. Reinforcing plates are added outside the heads and stiffeners are added inside the heads, greatly increasing tank body rigidity.
3. High working efficiency
Double helical blades with optimal design are used in the tank body to realize unloading at a low rotation speed and a high displacement.
Front cone of the tank body is fitted with 2 forced stirring blades to enhance mixing function and effectively prevent dilution.
4. It uses stoving varnish process and the complete truck looks nice and generous.
Parameters of complete vehicle and chassis |
Dimensions |
9400*2500*3990 |
Chassis model |
China National Heavy Duty Truck |
|
Engine model |
CNHTC WD615.95E |
|
Engine Power (KW/HP) |
247/336 |
|
Curb weight/rated load capacity (kg) |
15050/ 9820 |
|
Wheel base (mm) |
3800+1400 |
|
Tank parameters |
Agitating volume (cubic meter) |
10 |
Feed rate (cubic meter/minute) |
≥3.0 |
|
Discharge rate (cubic meter/minute) |
≥2.0 |
|
Discharging residual ratio (%) |
≤0.5 |
|
Mixing drum rotation speed (r/min) |
0—16 |
|
|
Hydraulic System |
ARK imported from Europe |
Welcome to consult us any question you have !
