YT5601GSS Performance Features
Compared with the conventional rigid mining vehicles, YT5601GSS has high cost performance, thereby saving vehicle acquisition expenses. In addition, it has comparable water volume and sprinkling performance, but its procurement cost is reduced by about 2/3.
Economic, reduce repeated trips – the water tank will be filled with 36m3 of water once, the sprinkling distance will be more distant, penses. In addition, it has comparable water volume and sprinkling performance, but its procurement cost is reduced by about 2/3. Mature chassis, stable and reliable technology – adopt the mature and stable YT3621 chassis dedicated for mining dump vehicle manufactured by Yutong Heavy Industries. Since its launching in 2010, its number cumulative sales have reached 2000, which has a number of advantages including good performance, low failure rate, and sufficient spare parts.
YT5601GSS Main technical parameters
YT5601GSS Main technical parameters | ||
Overall Vehicle Dimensions (L × W × H) |
Overall dimensions (L x W X H) |
9050×3200×4220mm |
Wheel Tread |
Wheelbase |
3600mm/1500mm |
Front Wheel Tread |
Front wheel distance |
2400mm |
Rear Wheel Tread |
Middle and rear wheel distance |
2264mm |
Water Tank Capacity |
Loaded Horizontally |
36m3 |
Complete Vehicle Kerb Mass |
Overall kerb weight |
24000kg |
Rated Loading Capacity |
Rated Load |
36t |
Maximum Speed |
Max. speed |
49km/h |
Maximum Gradeability |
Max. grade ability |
≥30% |
Minimum Turning Diameter |
Min. turning diameter |
≤21mm |
Minimum Ground Clearance |
Min. ground clearance |
380mm |
Approach/Departure Angle |
Approach angle/Departure angle |
27°/37° |
Water Pump Model |
|
80QZF60/90S |
Sprinkler Head |
|
Electronic Control in Cab |
Artesian Flow |
|
Equipped with artesian sprinkling device, controlled inside the cab |
Sprinkler Gun Distance |
|
≥30m |
Sprinklers Artillery Reach |
|
≥15m |
Spraying Width |
|
≥14m |
YT5601GSS mine-used sprinkler adopts the chassis for mining dump vehicle, and likewise changes the single propelling rod of the rear suspension into dual propelling rod, which is more reliable and durable; The rear part of the water tank is mounted with a water level gauge, so that the water level in the tank is directly observed, while retaining the low-level alarm device. Thus, the driver even in the cab can ascertain the water storage conditions in the water tank in order to feed water timely.
Welcome to consult us !
