Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm Dia.29-41mm
Negotiable
MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
IH22-C34-400, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm Dia.26-38mmNegotiableMOQ: 20 Pieces -
Plug Hole Integral Rod Hex 19, Shank 19 mm x 108 mmNegotiableMOQ: 20 Pieces
-
Alloy Steel Hex 19 Integral Drill RodNegotiableMOQ: 20 Pieces
-
Underground Mining Rock Carbide Drill RodNegotiableMOQ: 20 Pieces
-
Hexagonal Drill Extension RodNegotiableMOQ: 20 Pieces
Place of Origin
Shandong, China
Brand Name
MIROC
Model Number
IH22-C34-400, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm
Type
Other, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm Dia.29-41mm
Machine Type
Drilling Tool
Material
Carbon Steel
Processing Type
Forging
Use
Coal Mining
Specifications
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistanceHigh grade tungsten carb
Description
The H22 Integral drills steels, H22 x 108 mm shank, are the most common type within the Dimensional Stone Quarrying Industry. The product range includes a Ø26 - 40 mm bit diameters and lengths from 0.4 – 7.2 meters.
Application
• Dimensional Stone Quarrying Industry
• Underground Mining
• Tunneling
Specification
<
| Part Number | Product Code and Brief Description | Length (mm) | Length (ft/inch) | Bit Diameter (mm) | Weight (kg) |
| 4148300054 | IH22-C34-400, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 400 | 1 1/3 | 34 | 1.7 |
| 4148300055 | IH22-C33-800, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 800 | 2 5/8 | 33 | 3 |
| 4148300056 | IH22-C32-1200, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 1200 | 4 | 32 | 4.1 |
| 4148300057 | IH22-C31-1600, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 1600 | 5 1/4 | 31 | 5.2 |
| 4148300058 | IH22-C30-2000, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 2000 | 6 5/9 | 30 | 6.7 |
| 4148300059 | IH22-C41-600, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 600 | 2 | 41 | 2.4 |
| 4148300060 | IH22-C40-1200, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 1200 | 4 | 40 | 4.3 |
| 4148300061 | IH22-C39-1800, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 1800 | 6 | 39 | 6.2 |
| 4148300062 | IH22-C38-2400-2, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 2400 | 7 7/8 | 38 | 8 |
| 4148300063 | IH22-C41-400, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 400 | 1 1/3 | 41 | 1.7 |
| 4148300064 | IH22-C29-800, Chisel Bit Integral Rod Hex 22, Shank 22 mm x 108 mm | 800 | 2 5/8 | 29 | 3 |
