Help CenterAPI Reg Thread DTH Drill Pipe for Rock Drilling Tools
Related Products
-
F Thread 50-60mm DTH Drill Pipe for CNC ToolsNegotiableMOQ: 20 Pieces -
DTH Drill Pipe API Reg Thread 76-89mmNegotiableMOQ: 20 Pieces
-
F Thread DTH Drill PipeNegotiableMOQ: 20 Pieces
-
DTH Drill Pipes for Rock Drilling Tools/Borehole Drill ToolsUS$ 150 - 300MOQ: 1 Piece
-
F Thread Drill Pipes Out Diameter 50mm - 60mm for Rock Drilling ToolsUS$ 150 - 300MOQ: 1 Piece
Specifications
High strength steel with high fatigue strength and excellent wear resistance
• High grade steel used on thread area and main drill pipe body
In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.
DTH drilling enables drillers to reach hole depths that are double of what top hammer drilling can do. This is possible with the use of DTH Pipes and DTH Subs.
• Automated welding process used in joining the thread area and main drill pipe body
Color: Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: DTH Drill Pipe API Reg Thread
Applications
• Underground mining
• Quarry benching operations
• Water well drilling
Competitive Advantage
High strength steel with high fatigue strength and excellent wear resistance
| Part Number | Product Code and Brief Description | Outer Diameter (mm) | Outer Diameter (inch) | Thread | Drill Pipe Thickness (mm) | Drill Pipe Thickness (inch) | Length (mm) | Length (ft/inch) | Wrench Flat (mm) | Wrench Flat (inch) | Weight (kg) |
| 4148301544 | DTHP76-1000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 1000 | 3 2/7 | 57 | 2 1/4 | 17 |
| 4148301545 | DTHP76-1500, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 1500 | 5 | 57 | 2 1/4 | 22 |
| 4148301546 | DTHP76-2000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 2000 | 6 5/9 | 57 | 2 1/4 | 26 |
| 4148301547 | DTHP76-3000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 3000 | 9 5/6 | 57 | 2 1/4 | 35 |
| 4148301548 | DTHP76-1000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 1000 | 3 2/7 | 65 | 2 5/9 | 17 |
| 4148301549 | DTHP76-1500, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 1500 | 5 | 65 | 2 5/9 | 22 |
| 4148301550 | DTHP76-2000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 2000 | 6 5/9 | 65 | 2 5/9 | 26 |
| 4148301551 | DTHP76-3000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 5.5 | 2/9 | 3000 | 9 5/6 | 65 | 2 5/9 | 35 |
| 4148301552 | DTHP76-3000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 6.5 | 1/4 | 3000 | 9 5/6 | 65 | 2 5/9 | 46 |
| 4148301553 | DTHP76-4500, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 6.5 | 1/4 | 4500 | 14 3/4 | 65 | 2 5/9 | 56 |
| 4148301554 | DTHP76-6000, DTH Drill Pipe API Reg Thread | 76 | 3 | 2 3/8" API Reg | 6.5 | 1/4 | 6000 | 19 2/3 | 65 | 2 5/9 | 73 |
| 4148301555 | DTHP89-1000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 5.5 | 2/9 | 1000 | 3 2/7 | 65 | 2 5/9 | 20 |
| 4148301556 | DTHP89-1500, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 5.5 | 2/9 | 1500 | 5 | 65 | 2 5/9 | 25 |
| 4148301557 | DTHP89-2000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 5.5 | 2/9 | 2000 | 6 5/9 | 65 | 2 5/9 | 30 |
| 4148301558 | DTHP89-3000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 5.5 | 2/9 | 3000 | 9 5/6 | 65 | 2 5/9 | 40 |
| 4148301559 | DTHP89-1000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 1000 | 3 2/7 | 65 | 2 5/9 | 21 |
| 4148301560 | DTHP89-1500, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 1500 | 5 | 65 | 2 5/9 | 26 |
| 4148301561 | DTHP89-2000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 2000 | 6 5/9 | 65 | 2 5/9 | 32 |
| 4148301562 | DTHP89-3000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 3000 | 9 5/6 | 65 | 2 5/9 | 45 |
| 4148301563 | DTHP89-4500, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 4500 | 14 3/4 | 65 | 2 5/9 | 65 |
| 4148301564 | DTHP89-6000, DTH Drill Pipe API Reg Thread | 89 | 3 1/2 | 2 3/8" API Reg | 6.5 | 1/4 | 6000 | 19 2/3 | 65 | 2 5/9 | 84 |
Packaging:Carton or Wooden Box
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that has to be followed
- Significant differences in the way people work, mostly due o physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
