Description
• High grade steel used on thread area and main drill pipe body
• Automated welding process used in joining the thread area and main drill pipe body
Application
• Underground mining
• Quarry benching operations
• Water well drilling
| Part Number | Drill Pipe Thickness (mm) | Drill Pipe Thickness (inch) | Length (mm) | Length (ft/inch) | Wrench Flat (mm) | Wrench Flat (inch) | Weight (kg) |
| 4148301544 | 5.5 | 2/9 | 1000 | 3 2/7 | 57 | 2 1/4 | 17 |
| 4148301545 | 5.5 | 2/9 | 1500 | 5 | 57 | 2 1/4 | 22 |
| 4148301546 | 5.5 | 2/9 | 2000 | 6 5/9 | 57 | 2 1/4 | 26 |
| 4148301547 | 5.5 | 2/9 | 3000 | 9 5/6 | 57 | 2 1/4 | 35 |
| 4148301548 | 5.5 | 2/9 | 1000 | 3 2/7 | 65 | 2 5/9 | 17 |
| 4148301549 | 5.5 | 2/9 | 1500 | 5 | 65 | 2 5/9 | 22 |
| 4148301550 | 5.5 | 2/9 | 2000 | 6 5/9 | 65 | 2 5/9 | 26 |
| 4148301551 | 5.5 | 2/9 | 3000 | 9 5/6 | 65 | 2 5/9 | 35 |
| 4148301552 | 6.5 | 1/4 | 3000 | 9 5/6 | 65 | 2 5/9 | 46 |
| 4148301553 | 6.5 | 1/4 | 4500 | 14 3/4 | 65 | 2 5/9 | 56 |
| 4148301554 | 6.5 | 1/4 | 6000 | 19 2/3 | 65 | 2 5/9 | 73 |
| 4148301555 | 5.5 | 2/9 | 1000 | 3 2/7 | 65 | 2 5/9 | 20 |
| 4148301556 | 5.5 | 2/9 | 1500 | 5 | 65 | 2 5/9 | 25 |
| 4148301557 | 5.5 | 2/9 | 2000 | 6 5/9 | 65 | 2 5/9 | 30 |
| 4148301558 | 5.5 | 2/9 | 3000 | 9 5/6 | 65 | 2 5/9 | 40 |
| 4148301559 | 6.5 | 1/4 | 1000 | 3 2/7 | 65 | 2 5/9 | 21 |
| 4148301560 | 6.5 | 1/4 | 1500 | 5 | 65 | 2 5/9 | 26 |
| 4148301561 | 6.5 | 1/4 | 2000 | 6 5/9 | 65 | 2 5/9 | 32 |
| 4148301562 | 6.5 | 1/4 | 3000 | 9 5/6 | 65 | 2 5/9 | 45 |
| 4148301563 | 6.5 | 1/4 | 4500 | 14 3/4 | 65 | 2 5/9 | 65 |
| 4148301564 | 6.5 | 1/4 | 6000 | 19 2/3 | 65 | 2 5/9 | 84 |
Part Number |
Product Code and Brief Description |
Outer Diameter (mm) |
Outer Diameter (inch) |
Thread |
4148301544 |
DTHP76-1000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301545 |
DTHP76-1500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301546 |
DTHP76-2000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301547 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301548 |
DTHP76-1000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301549 |
DTHP76-1500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301550 |
DTHP76-2000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301551 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301552 |
DTHP76-3000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301553 |
DTHP76-4500, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301554 |
DTHP76-6000, DTH Drill Pipe API Reg Thread |
76 |
3 |
2 3/8" API Reg |
4148301555 |
DTHP89-1000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301556 |
DTHP89-1500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301557 |
DTHP89-2000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301558 |
DTHP89-3000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301559 |
DTHP89-1000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301560 |
DTHP89-1500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301561 |
DTHP89-2000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301562 |
DTHP89-3000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301563 |
DTHP89-4500, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
4148301564 |
DTHP89-6000, DTH Drill Pipe API Reg Thread |
89 |
3 1/2 |
2 3/8" API Reg |
Company Profile
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that has to be followed
- Significant differences in the way people work, mostly due o physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
