Henan Yuding Electronics Corp., Ltd.: Zhengzhou, Henan, China; Main products: radio remote control, wireless remote control, crane remote control, telecrane remote control, industrial remote control

Home > Products > F24 Series Remote Control > Wireless Crane Radio Remote Control

Wireless Crane Radio Remote Control

Name: Wireless Crane Radio Remote Control
Brand: electronic
Availability: InStock

FOB Price

US$ 99 - 240 / Piece

1 Piece(Min. Order)

Port Zhengzhou Beijing Tianjin Shenzhen Shanghai etc
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	electronic		Model Number	F21-6D
Use	Universal		Place of Origin	Henan, China

Product Description

Wireless Crane Radio Remote Control

Picture:

Wireless Crane Radio Remote Control :

TX Model	F21-6D-TX-V-(E)
TX Size	about 18.8x6.4x4.8(cm)
TX Weight	about 293g(without Batteries)
Housing Materail	glass fiber-reinforced nylon-6
Protection Degree	IP65
Temperature Rating	-35°C ~ +85°C(Regardless of the battery temperature tolerance)
TX power Supply	Two 1.5 volts Batteries(AA Size)
Number of buttons	6 Double speed buttons,1 START button, 1 mushroom button,1Rotary switch
Button Marking	arrow tip
I.D.Code	4.3 billion
Voltage Warning	TX Red LED will flash slowly when the volts under 2.2V,and unable to start TX under 1.8V.
Voltage Warning
Operating Frequency	310.0325-331.165MHz
Channel Spacing	0.2675MHz
Channel	80CH
RF Power	<10DBm
Fault Detection	TX Red LED is flashing quickly: 1.Not in the correct way to start; 2.One of the pushbutton is jammed. TX LED will flash slowly: 1.Please change two new batteries

RX Model	F21-6D-RX-V-(E)
RX Size	17.0x16.7x8.7cm
RX Weight	about1173g
Housing Material	glass fiber-reinforced nylon-6
Protection Degree	IP65
connection diagram	english
Temperature Rating	-35°C ~ +85°℃
Power Supply	AC380V,AC36V,AC220V,AC110V,AC48V, AC24V,AC12V/DC12V,AC380V/AC220V(50-60Hz)
Relays	10 Relays control functions,1 relay control EMS and 1 relay reserve
Output Relays	5Amp Omniseal Relays(AC250V/10A Relays, 10Amp fuse)
I.D.Code	4.3 billion
Operating Frequency	310.0325-331.165MHz
Channel Spacing	0.2675MHz
Channel	80CH
Sensitivity	≥-110DBm
Interface	Cable output

Standard Configuration:

* It suitable for single hook single speed electric hoist type crane and the application of under 8 contacts

* industrial remote control.

* One Transmitter 1pcs(with straps);

* One Receiver;

* One Receiver with 1meter cable ;

* Operation and Maintenance manual;

>> Wiring diagram

--------------------------------------------------------------------------------------------

Package include:

Transmitter x1 (with strap)

Receiver x1 (receiver comes with 1 m connection cable)

Operation and maintenance manual x1

Instruction:

1. Depress the TX Emergency Stop or remove the magnetic key

2. Press UP push button and hold it.

3. Start the system as usual.

Application:

The ranges of applications of our industrial radio remote control system

1. Overhead bridge cranes,

2. Gantry crane

3. Beam launcher

4. Monorail hoists,

5. Motorized jib cranes

6. Other pieces of industrial equipment.

ABOUT YUDING:

HeNan Yuding Electronics Corp., Ltd is an industrial radio remote controls manufacturer in china .With more than 10 years experience on this industrial remote control system business area. headquartered in Zhengzhou, Henan province.

Yuding has so many experts in the industrial radio remote controller area to assure workers safety and productivity , Yuding are becoming one of the leading companies in this industry in china.

Our main products is :F21 Series Wireless Crane Radio Remote Control ,F23 series radio remote controls ,F24-60 Dual Joystick radio remote control .

FAQ

1. Q:What is your MOQ?

1pc as sample for trial order is available.

2. Q:Is there any warranty?

A: all of our products enjoy 1 year warranty, also. technical support and after-service for our product can offer to you at any time after you bought.

3. Q:Will you provide the after-sales?

A:Of course

1)All products have been aging for 12hours before packing.
2) Wireless Crane Radio Remote Control have been well packed in our factory, and the second packaging by express service before shipping.
3)If any problem during operation or installation, please contact us freely, we will solve with professional instruction.

4. Q:Which certificates do your products approve?

A: CE,FCC,ISO, etc

5. Q:What’s the control distance for F21 Series Industrial radio remote controls?

A: Usually 100Mts is ok

6. Q:Have product 100% assembled well in stock?

A:Yes, all the products are 100% assembled well.

Waiting for your kind inquiry !
