Specifications
1.type:Waste PE Film Recycling Machine2.capacity:500kg/h
3.power:90kw
4.CE certification
5.reasonable price
Waste PE Film Recycling Machine
Features:
1) Environmentally friendly composite plastic-cellulose fiber materials
2) The knievs can be shaped using carpentry and construction tools
3) Applications: Indoor decoration film, packing film, pallet making production, agricultural film etc.
4) Capacity: 300-1000kg/h
5) Use: Clean PE PP film, dirty PP PE film, PP PE film with oil.
We can design a complete films washing line according to your request.
Waste PE Film Recycling Machine machine list:
1. Belt conveyor: Convey material to next process.
2. Crusher: Crush the materials to flakes of 15mm (two series: one for PET, one for PP/PE)
3. Friction washer: Surface clean the materials (two series: one for PET, one for PP/PE), and transport material to next washing equipment.
4. Float Washing tank: For separation of the flakes with a specific density of <1g/cm^3 from >1g/cm^3 or in contrast to separate the flakes with a specific of > 1g/cm^3 form <1g/cm^3 (PET >1g/cm^3 and PP/PE <1g/cm^3)
5. Screw feeder: transport material and as well as for rub them for surface cleaning.
6. Dewatering machine: for mechanical surface drying of the material flakes with rotating roller (two series: one for PET, one for PP/PE)
7. Air cyclone drying system: Using stainless steel “U” type pipeline and cyclone silo to dry the material to the necessary residual level for downstream material processing.
8. Cyclone silo: Storage for final products.
Waste PE Film Recycling Machine process flow:
Waste PE Film Recycling Machine technical data:
| WASTE PE. PP FILM CRUSHING WASHING LINE(OUTPUT: 500-700kg/hr) | |||||
| NO | component items | POWE(kw) | L*W*H(mm) | WEIGHT (kg) | QTY |
| 1 | Belt conveyor | 1.5 | 6000*900*600(3200) | 600 | 1 |
| 2 | PS-1000 Crusher with water | 45 | 1650*1660*2800(2800+920) | 1700 | 1 |
| 3 | Screw Loader 1(Φ 500) | 11 | 3500*800*1300 | 700 | 1 |
| 4 | Single Screw friction washing | 11+0.75 | 5300*1300*2150 | 2200 | 1 |
| 5 | Screw Loader 2(Φ 500) | 11 | 3500*800*1300 | 700 | 1 |
| 6 | Floating Tank | 2.2+1.1+1.5 | 6000*1200*2150 | 2300 | 1 |
| 7 | Screw Loader 3(Φ 500) | 11 | 3500*800*1300 | 700 | 1 |
| 8 | Horizontal dryer | 30 | 2300*1750*1900 | 2200 | 1 |
| 9 | Silo | 1500*900*3400 | 130 | 1 | |
| 10 | electrical control system | 800*500*2000 | 520 | 1 | |
| 1000*550*1150 | 120 | 1 | |||
|
1, length of production line: 27 m; 2, installed power: 128 kw; 3, equipment noise: 1 meter≤ 80dB; 5 meters≤ 75dB; 4, water consumption for recyling 1T waste material: 1m³ (circulating water); 5, oil burning boiler steam volume: 300kg/h ; steam pressure 0.7MPa; vapor temperature: 170° C; average oil consumption per hour: 15-25L; | |||||
Waste PE Film Recycling Machine chart:
After Service:
We have 1 year warranty, and lifetime maintenance.
Within one year, if there is some accessory going wrong, we will send you the accessory at once, free of charge.
1). Within one month, if the machine is of any big fails, we will send you a new machine.
2). Within one year, if you send back the equipment for repair, we will be responsible for the repair, including the changes of accessories; Both of them are free of charge.
3). After one years, we offer to repair the machine, but we quire for the cost of the changed parts, not for manual cost.
4). No responsibility for man-made destroy.
5). If the buyer has any questions from our technical department, we can supply on-line service Or we can send professional engineers to help you debug them.
If you are interested in our machine,please feel free to contact us.
Thanks and best regards.
