Hot Sale PPR Drain Pipe Extrusion Line
Application:
1. The pipes are based on high density PE as main raw material.
2. This kind of HDPE Large diameter pipe production line has many advantages, such as corrosion resistant light, easy to fix, long time to use etc.
3. The pipes are widely used in high-way, municipal constructional, flats and so on.
Hot Sale PPR Drain Pipe Extrusion Line ----data sheet:
|
Model
|
Screw diameter |
L/D |
Pipe range(mm) |
Main motor power (kw) |
Total power(kw) |
Line length (mm) |
|
PPR-63
|
65mm |
33:1 |
16-63 |
37 |
80 |
24 |
|
PPR-110
|
65mm |
33:1 |
75-110 |
55 |
110 |
30 |
|
PPR-160
|
75mm |
33:1 |
90-160 |
90 |
150 |
32 |
|
PPR-315
|
90mm |
33:1 |
160-315 |
160 |
240 |
44 |
Hot Sale PPR Drain Pipe Extrusion Line -----detail information:
1. Automatic feeding and drying system: vacuum sucking up and automatic controlling hot air heating.
2. Single screw extruder: high speed extruders adopts notched barrel (with water forced cooling transportation zone), shielded screw with special mixing structure ensures the stability of high extruding and the plasticizing quality.
3. Electrical control system: Siemens PLC, ABB converter, Omron temperature controller. The entire production line adopts the originally imported new control system of PLC programmable computer, guaranteed highly and steadily reliable controls of the production line.
4. Die head: specially structured spiral accumulator-type die head surmounts stress orientation of polymer chain during pipe forming and achieve smooth-pressure extruding, and makes the good physical and chemical properties of raw material be copied into the pipe, meanwhile the stability of the extruding pressure is the strong guarantee for high-speed manufacturing.
5. Vacuum calibration tank: vacuum calibrating mandrel adopts our own proprietary’s mult-sheet water immersion calibrating mandrel (invention patents, practical new patents), realized the cooling calibrating evenly and effectively for plastic pipe, ensuring high speed production of the pipe.
6. Haul-off machine: high speed flat belt pulling machine with multi-group roll wheel is specially designed for high speed pipe production, which can ensure the stable running during the production no matter at high or low speed.
Hot Sale PPR Drain Pipe Extrusion Line ---- process flow:
How to get your suitable machine or production line ?
• Find our products through in Google ,Baidu. Bing ,Yahoo, etc
•Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trademanager, MSN, Skype) and let us know your enquiry.
• Discussion: Specify the items you desire, confirm specification; OEM/ODM consultation.
1.What kind of products will you produce?Pipe,Plastic profile,or Sheet?
2. What is raw material like?Granule type or powder type?
3. What kind of material ?PE,PVC,PPR,HDPE,UPVC:Pipe diameter, or other please inform us of details .
4. Sole machine or whole production line .
• Quotation: Prices offered and accepted.
• Place order as per contract or discussion.
• Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
• Payment settled.
• Order completed under our arrangement.
• Goods shipped as per contracted term.
• Goods arrive at local port or warehouse, depending on contracted term.
• Support & re-ordering.
After Service:
We have 1 year warranty, and lifetime maintenance.
Within one year, if there is some accessory going wrong, we will send you the accessory at once, free of charge.
1). Within one month, if the machine is of any big fails, we will send you a new machine.
2). Within one year, if you send back the equipment for repair, we will be responsible for the repair, including the changes of accessories; Both of them are free of charge.
3). After one years, we offer to repair the machine, but we quire for the cost of the changed parts, not for manual cost.
4). No responsibility for man-made destroy.
5). If the buyer has any questions from our technical department, we can supply on-line service Or we can send professional engineers to help you debug them.
If you are interested in our plastic pipe extrusion,please feel free to contact us,we will satisfy you upon receipt of your reply,as we donot want to lose a good customer like you.
