Help CenterKS-55T-C China Vertical Plastic Injection Machine Factory
Related Products
Specifications
1.vertical plastic injection machine2.factory built:in 1996
3.address:changan town,dongguan(near to guangzhou)
KS-55T-C vertical plastic injection machine
Oil pressure spares:
Oil motor--------------------------------------Intermot Hydraulic Pressure Ltd.,Italy
Metering pumps dosing-----------------Hai Teke Hydraulic Co.,Ltd. Taiwan
Electromagnetic selector valve------Seven Sea Hydraulic Co,.Ltd. Japan
Semi-closure valve control------------Germany Dr.Rexroth Inc.
Hydraulic valve-----------------------------Hai Teke Hydraulic Co.,Ltd. Taiwan
Electric spares:
Temperature sensing wire--------------Arico (TW) Ltd.
Solid State Relay(SSR)-------------------Taihua (TW) Company
Electronic ruler-------------------------------Mrian (SW) Ltd.
Press stopper---------------------------------AP (TW) Company
Others:
Electronic motor-----------------------------Global Electric Machinery Ltd.
Sealing-------------------------------------------Japan NOK Joint-Stock-Cooperation
Feed pipe group------------------------------Taiwan General Machinery Company
Oil pipe-------------------------------------------Italy ALFA Company
Oil cylinder-------------------------------------Taiwan Jiangjun Machinery Company
| Model | Unit | KS-55T-C |
| Screw Diameter | mm | 30 | 32 | 42 |
| Injection Pressure | Kg/cm² | 1742 | 1531 | 889 |
| Theoretical Shot Volume | cm³ | 113 | 129 | 222 |
| (ps) Max.shot Weight(ps) | G/oz | 104 | 118 | 204 |
| Injection Rate | cm³/sec | 93 | 105 | 181 |
| Number of Temperature Control | zone | 4 |
| Clamping Force | Tons | 55 |
| Opening Force | Tons | 8.4 |
| Platen Size | mm | 580*280 |
| Distance Between Tie Bare | mm | |
| Min.Mold Height | mm | 200 |
| Oprening Stroke | mm | 230 |
| Ejector Force | Tons | 1.2 |
| Ejector Stroke | mm | 120 |
| Max.Hydaulic Pressure | Kg/cm² | 140 |
| Pump Output | Liters/min | 69 |
| Pump Motor Power | kw/HP | 11/15 |
| Barrel Heating Power | kw | 6.5 |
| Machine Weight | Tons | 3.2 |
| Machine Dimensions(L×W×H) | m | 2.8*1.0*2.0 |
| Shipping Measurements(L×W×H) | m | 3.0*1.2*2.2 |
Configuration table
| Oil pressure spares: | ||||||||
| oil pump | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| oil motor | U.S. WHITE Group | |||||||
| electromagnetic selector valve | Japan YUKEN CO.,LTD. | |||||||
| proportional valve | Japan YUKEN CO.,LTD. | |||||||
| semi-closure valve controller | Germany Dr.Rexroth INC. | |||||||
| hydraulic valve | Taiwan Hai Teke Hydraulic CO.,LTD. | |||||||
| Electric spares: | ||||||||
| computer controller | Procheson Technology CO.,LTD. | |||||||
| temperature sensing wire | Taiwan Arico CO.,LTD. | |||||||
| SSR | Taiwan Yangming CO.,LTD. | |||||||
| electric ruler | Switzerland Mrian CO.,LTD. | |||||||
| power switch | Mitsubishi | |||||||
| Others: | ||||||||
| electronic motor | Global Electric Machinery LTD. | |||||||
| sealing | Japan NOK Joint-Stock-Cooperation | |||||||
| feed pipe group | Taiwan Tianxing CO.,LTD. | |||||||
| tie bar | Taiwan Jiangjun Machinery CO. | |||||||
| oil pipe | Italy ALFA CO. | |||||||
| oil cylinder | Taiwan Jiangjun Machinery CO. | |||||||
