Home > Manufacturing & Processing Machinery > Plastic Machinery > Blow Molding Machine > KS-85T-C Vertical Injection Machine

KS-85T-C Vertical Injection Machine

Name: KS-85T-C Vertical Injection Machine
Brand: kasun
SKU: 118836945

KS-85T-C Vertical Injection Machine thumbnail-1

KS-85T-C Vertical Injection Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Application:

Other, electric parts,shoe sole

Plastic Processed:

PET

Contact Supplier Request Quote Chat Now

Dongguan Jiaxingchang Mechanical Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Other, electric parts,shoe sole

Plastic Processed PET

Automatic Yes

Place of Origin Guangdong, China

Brand Name kasun

Model Number KS-85T-C

Voltage 380V

Dimension(L*W*H) 3.2*1.2*2.3m

Weight 4.5tons

Certification ISO9000

Warranty 1 year

Specifications

1.vertical injection machine
2.factory built:in 1996
3.address:shatou district,changan town ,dongguan

KS-85T-C vertical injection machine

Injection section:

double guiding rod supporting

double dro-cylinder balance injection

linear displacemet transducer accurately monitor injection position

heating status indication

Computer-control:

PLC control

digital memory for mold group

automatic alarm

Hydraulic unit:

Japan YUKEN

system pressure is controlled through proportional valves

Clamping unit:

fine-element analysis used to design platen

adjustable mechanical support system used for moving platens to protect tie bars

Other parts:

shot counter and reset function

malfunction alarm light

self-diagnostic function

emergency stop buttons placed both front and rear of the machine to easy access

Model

Unit

KS-85T-C

Screw Diameter	mm	32	42	45
Injection Pressure	Kg/cm²	2625	1524	1327
Theoretical Shot Volume	cm³	145	249	286
(ps) Max.shot Weight(ps)	G/oz	133	229	263
Injection Rate	cm³/sec	68	118	135

Number of Temperature Control	zone	4
Clamping Force	Tons	85
Opening Force	Tons	11
Platen Size	mm	630*335
Distance Between Tie Bare	mm
Min.Mold Height	mm	220
Oprening Stroke	mm	250
Ejector Force	Tons	1.5
Ejector Stroke	mm	120
Max.Hydaulic Pressure	Kg/cm²	140
Pump Output	Liters/min	77
Pump Motor Power	kw/HP	15/20
Barrel Heating Power	kw	7.6
Machine Weight	Tons	4.5
Machine Dimensions(L×W×H)	m	3.21.22.3
Shipping Measurements(L×W×H)	m	3.41.42.5

Configuration table

Oil pressure spares:
oil pump				Taiwan Hai Teke Hydraulic CO.,LTD.
oil motor				U.S. WHITE Group
electromagnetic selector valve				Japan YUKEN CO.,LTD.
proportional valve				Japan YUKEN CO.,LTD.
semi-closure valve controller				Germany Dr.Rexroth INC.
hydraulic valve				Taiwan Hai Teke Hydraulic CO.,LTD.

Electric spares:
computer controller				Procheson Technology CO.,LTD.
temperature sensing wire				Taiwan Arico CO.,LTD.
SSR				Taiwan Yangming CO.,LTD.
electric ruler				Switzerland Mrian CO.,LTD.
power switch				Mitsubishi

Others:
electronic motor				Global Electric Machinery LTD.
sealing				Japan NOK Joint-Stock-Cooperation
feed pipe group				Taiwan Tianxing CO.,LTD.
tie bar				Taiwan Jiangjun Machinery CO.
oil pipe				Italy ALFA CO.
oil cylinder				Taiwan Jiangjun Machinery CO.
