KS-55T-R Servo Motor Injection Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Vertical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KS-85T-RVV Small Plastic InjectionNegotiableMOQ: 1 Set -
KS-55T-R Phenolic Injection MachineNegotiableMOQ: 1 Set
-
KS-85T-RVV Small Products Manufacturing MachinesNegotiableMOQ: 1 Set
-
KS-55T-R BMC Series Vertical Injection Molding MachineNegotiableMOQ: 1 Set
-
KS-55T-R Plastic Injection Molding Machine PriceNegotiableMOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Vertical
Brand Name
kasun
Model Number
KS-55T-R
Place of Origin
Guangdong, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
130-187g
Injection Rate
104-135cm3/sec
Clamping Force
55tons
Opening Stroke
215mm
Certification
ISO9000
Specifications
1.plastic injection molding machine2.LCD display
3.PLC control
4.energy saving:30%-50%
5.ISO9000
KS-55T-R injection moulding machine
Disk Unit
Injection section:
double guiding rod supporting
cold start protection
linear displacement transducer accurately monitor injection position
heating status indication
Computer-control:
PLC control
digital memory for mold group
Hydraulic unit:
Japan YUKEN
Clamping unit:
fine-element analysis used to design platen
Other parts:
shot counter and reset function
malfunction alarm light
self-diagnostic function
emergency stop buttons placed both front and rear of the machine to easy access
| Model | Unit | KS-55T-R |
| Screw Diameter | mm | 30 | 32 | 36 |
| Injection Pressure | Kg/cm² | 1742 | 1331 | 1210 |
| Theoretical Shot Volume | cm³ | 113 | 129 | 163 |
| (ps) Max.shot Weight(ps) | G/oz | 130 | 148 | 187 |
| Injection Rate | cm³/sec | 104 | 118 | 135 |
| Number of Temperature Control | 4 | |
| Clamping Force | Tons | 55 |
| Opening Force | Tons | 9.2 |
| Platen Size | mm | 300*250 |
| Distance Between Tie Bare | mm | 350*970 |
| Min.Mold Height | mm | 180 |
| Oprening Stroke | mm | 215 |
| Ejector Force | Tons | 1.2 |
| Ejector Stroke | mm | 120 |
| Max.Hydaulic Pressure | Kg/cm³ | 140 |
| Pump Output | Liters/min | 69 |
| Pump Motor Power | kw/HP | 11/15 |
| Barrel Heating Power | kw | 6.5 |
| Machine Weight | Tons | 4.9 |
| Machine Dimensions(L×W×H) | m | 2.1*1.9*3.0 |
| Shipping Measurements(L×W×H) | m | 2.3*2.1*3.2 |
| Slide stroke | mm | 2/3 |
| Diameter of disk | mm | 980 |
| Station clearance | mm | 0.05 |
