Home > Products > KS-T-R Disk unit > KS-55T-R BMC Series vertical injection molding machine
KS-55T-R BMC Series vertical injection molding machine
- 50 Set / Sets per Month
- Shenzhen
- T/T Credit Card
Product Details
Condition: | New | Type: | Preform Injection | Style: | Vertical |
Brand Name: | kasun | Model Number: | KS-55T-R | Place of Origin: | Guangdong, China |
Plastic Type: | Thermoplastic | Automatic: | Yes | Injection Weight: | 130-187g |
Injection Rate: | 104-135cm3/sec | Clamping Force: | 55tons | Opening Stroke: | 215mm |
Certification: | ISO9000 |
Product Description
Specifications
1.plastic injection molding machine2.LCD display
3.PLC control
4.energy saving:30%-50%
5.ISO9000
KS-55T-R injection moulding machine
Disk Unit
Injection section:
double guiding rod supporting
cold start protection
linear displacement transducer accurately monitor injection position
heating status indication
Computer-control:
PLC control
digital memory for mold group
Hydraulic unit:
Japan YUKEN
Clamping unit:
fine-element analysis used to design platen
Other parts:
shot counter and reset function
malfunction alarm light
self-diagnostic function
emergency stop buttons placed both front and rear of the machine to easy access
Model | Unit | KS-55T-R |
Screw Diameter | mm | 30 | 32 | 36 |
Injection Pressure | Kg/cm² | 1742 | 1331 | 1210 |
Theoretical Shot Volume | cm³ | 113 | 129 | 163 |
(ps) Max.shot Weight(ps) | G/oz | 130 | 148 | 187 |
Injection Rate | cm³/sec | 104 | 118 | 135 |
Number of Temperature Control | 4 | |
Clamping Force | Tons | 55 |
Opening Force | Tons | 9.2 |
Platen Size | mm | 300*250 |
Distance Between Tie Bare | mm | 350*970 |
Min.Mold Height | mm | 180 |
Oprening Stroke | mm | 215 |
Ejector Force | Tons | 1.2 |
Ejector Stroke | mm | 120 |
Max.Hydaulic Pressure | Kg/cm³ | 140 |
Pump Output | Liters/min | 69 |
Pump Motor Power | kw/HP | 11/15 |
Barrel Heating Power | kw | 6.5 |
Machine Weight | Tons | 4.9 |
Machine Dimensions(L×W×H) | m | 2.1*1.9*3.0 |
Shipping Measurements(L×W×H) | m | 2.3*2.1*3.2 |
Slide stroke | mm | 2/3 |
Diameter of disk | mm | 980 |
Station clearance | mm | 0.05 |
