2015 Fingerprint Time Attendance System
|
AC110 is a biometric fingerprint time attendance terminal with battery backup function, it can be upgraded to access control function as well. Its hardware structure adopts structured design of industrial grade. Front case is acrylic and wire drawing process for the frame of display, back case is with metal paint process, so it shows classical style. It is with ourselves fingerprint arithmetic which is the most advanced one in the world, automatically analyze the tiny difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for injured and peeled fingers, the identification time is less than 0.8 second. With ID card(optional for IC card) function, multi validation methods by card, fingerprint and password combination. Standalone to operate the device, U flash drive could realize all kind of setting for the device directly. TCP/IP communication, network connection is simple and convenient. Support Push Technology, data collection & sharing freely. Optional for battery backup function and access control function. |
|
* With the most advanced fingerprint arithmetic in the world automatically analyze the tiny difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for injured and peeled fingers, the identification time is less than 0.8 second.
* Built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password combination.
* 2.8 inch TFT color screen
* Support U disk to download or upload attendance records and fingerprint data ect. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory.
* TCP/IP communication, network connection is simple and convenient, support Push Technology, operate access control networking and data collection & sharing freely
* Supports 11 & 18 digits for user ID registration, user also could enroll mobile number for ID numbers.
* Authentication modes are 1:1 and 1:N, user can register ten fingers, max fingerprint capacity is 1,500 enrollment and 100,000 records. Warning function for full records and inquiry log functions.
* Could upgrade to simple access control function and battery backup function
* Support multi development language(VB, C++, C#, Delphi ect) SDK, and ODM/OEM software development
* Support English, Germany, Spanish ect different languages. |
Model |
AC110 |
LCD Screen |
2.8 inch TFT Color Screen |
Fingerprint Sensor Resolution |
500DPI (Optical sensor) |
Hardware Platform |
AC2911 |
Algorithm Version |
RSFv5.1 |
CPU |
ARM926EJ CPU, Running Frequency: 200MHZ |
Communication |
TCP/IP, USB Memory Disk, USB cable |
User Capacity |
2,000 |
Records Capacity |
100,000 |
Software OS |
XP/Win2003/Vista/Win7/Win8 (32bit / 64bit) |
Identification Time |
< 1 S |
Authentication Method |
Fingerprint/ RFID Card (125Khz, EM4100) /Password |
Language |
Chinese / English / Spanish/Arabic/ German (could customize others) |
Bell |
Built-in timing bell |
Operation Mode |
Off-line/Online |
Power |
DC 12V/0.5A |
FRR |
<1% |
FAR |
<0.00001% |
Operating Mode |
Off-line/On-line |
Authentication Mode |
1:1, 1:N |
Operating environment |
Operating Temp: 0°C-50°C, Humidity:80% |
Dimension(L*W*H)mm |
Terminal – 190*140*41.5mm Package –325*105*258mm |
Weight |
Terminal – 0.376 Kg Package – 0.939Kg |
Software Language: Chinese, English, Arabic, Spanish, French, Thai, Portoguese
