Intelligent Fingerprint Time Attendance Device With Super Capacity

DC1534ID is a built-in Linux system and intelligent RIFD and fingerprint attendance time terminal

with super capacity, it’s with the most advanced fingerprint arithmetic in the world, and adopts

structured design & electronic components for industrial grade, it is 3.5 inch 64K TFT color

screen. To store 5,000 fingerprint enrollments and 100,000 records, can download or upload

data by U flash memory, TCP/IP communication, message and meeting notification functions, very suitable for medium to large companies.

* With the most advanced fingerprint arithmetic in the world, automatically analyze the tiny

difference of the latest fingerprints vs. the precious fingerprints and update accordingly to ensure

the high accuracy and the optimum speed of fingerprint recognition. High recognition ability for

injured and peeled fingers, the identification time is less than 1 second.

* Built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password

combination, access control is more flexible and secure.

* 3.5 inch 64K TFT color screen

* Support U disk to download or upload attendance records and fingerprint data ect. User could

enroll the fingerprint in one device, and share the enrollment information with other devices

through the USB flash memory.

* TCP/IP communication, network connection is simple and convenient, support Push

Technology, operate access control networking and data collection & sharing freely

* Authentication modes are 1:1 and 1:N, user can register three fingers, max fingerprint capacity

to store 5,000(optional to 10,000) enrollment and 100,000 records. With full record warning and

log inquiry function.

Model

DC1534ID

LCD Screen

3.5 inch TFT( 320*240)

Fingerprint Sensor Resolution

500DPI (Optical sensor)

Hardware Platform

AC2911

Algorithm Version

RSFv5.1

CPU

ARM926EJ CPU, Running Frequency: 200MHZ

Communication

TCP/IP, USB Memory Disk, USB cable

User Capacity

5,000(can upgrade to 10,000)

Records Capacity

100,000

Software OS

XP/Win2003/Vista/Win7/Win8 (32bit / 64bit)

Identification Time

< 1 S

Authentication Method

Fingerprint/ RFID Card (125Khz, EM4100) /Password

Language

Chinese / English / Spanish/Arabic/ German (could customize others)

Bell

Built-in timing bell

Operation Mode

Off-line/Online

Power

DC 12V/0.5A

FRR

<1%

FAR

<0.00001%

Operating Mode

Off-line/On-line

Authentication Mode

1:1, 1:N

Operating environment

Operating Temp: 0-50C, Humidity:80%

Dimension(L*W*H)mm

Terminal – 190*140*37mm

Package – 325*103.5*255mm

Weight

Terminal – 0.455 Kg

Package – 1.117Kg
