Application:
These cables are used for separate earth conductors, switchboard and control panel wiring. For
fixed wiring within other enclos ures or apparatus where the cabl e is not accessible without the
use of tools
1. U0/U: 0.6/1KV
2. Standard Applied: AS/NZS 5000.1
3. ing temperature: 90°C, can be 110 °C as per requirement
4. Conductor: Class 1/2 Plain annealed copper wires, solid or stranded
5. Cross section area: Single core:1.0 mm2~ 150 mm
6. Insulation: V-90 PVC
7. Cores: Single core .
8. Color: black or as per requirement
9. Flame retardant or Fire resistance or Low smoke and halogen free or other property can be available.
10. Packing: 100 meter/roll or as per requirement
11. Certification: ISO9001, ISO14001, OHSMS18001, CE, CB, CCC, SAA,etc.
12. OEM can be available
13. BDK cables have very good sales over the world, enjoying a very good reputation based on top quality and most competitive price and service.
Main manufacturing procedure:
1. Copper wire drawing and annealing
2. Copper wire stranding
3. V-90 PVC insulation extruding
6. Outer labeling
7. 100 meter/roll / Wooden drum or as per requirement
Main Quality Inspection Equipments:
–Spark tester –Heating aging chamber –High resistance machine –Oxygen index equipment –Partial discharge inspection instrument –fire proof testing device –High-power voltage withstand tester –No-rotor voltammeter –Pull tester –Analytical balance –Direct current bridge –Plastic tester –Projector –Punch machine –Cross-linked cutting machine etc.
