PVC insulated Australia Standard flexible cable . These cables are used for ease of installation in switchboards and control panels where confined spaces and tortuous routes are encountered, or where flexibility is needed for hinged panels, also for fixed wiring within other enclosures where the cable is not accessible without the use of tools. Hand held lights and other appliances.
General Information:
Rated Voltage : 300/500V, 0.6/1KV
Cores: 2C, 3C, 4C, 5C, 2C+E, 3C+E, 4C+E
Range of Nominal cross section: 0.75 mm2 ~ 4.0 mm2
Standard : AS/NZS 3191
Conductor: Class 5 fine annealed copper wires
Insulation: V-90 PVC
Sheath: 5V-90 PVC
Max. Operating Temperature : 90℃
Main manufacturing procedure:
1. Copper wire drawing and annealing
2. Copper wire stranding
3. PVC insulation extruding
4. PVC sheath extruding
5. Spooling
