Flexible Cable To AS/NZS 3191
These cables are used for ease of installation in switchboards and control panels where confined spaces and tortuous routes are encountered, or where flexibility is needed for hinged panels, also for fixed wiring within other enclosures where the cable is not accessible without the use of tools. Hand held lights and other appliances.
Specifications:
1. Voltage rating: 300/500V, 600/1000V
2. Conductor: Class 5 fine annealed copper wires
3. Insulation: V-90 PVC
4. Sheath: 5V-90,
5. Normal operating temp.: 90°C
6. Standard applied: AS/NZS 3191
7. Max. operating temp.: 90°C
8. Cores: 2C, 3C, 4C, 5C, 2C+E, 3C+E, 4C+E
9. Cross section area:1.5 mm² ~ 300mm²
10. Color: Red,black,blue,white for active core, green/yellow for earth core, black or grey or orange for sheath
11.Remark: Flame retardant or fire resistance or Low Smoking and Halogen free or other property can be available
12: Package:100 meters per roll or as per requirement
13.Certification:ISO9001,ISO14001,OHSMS18001,CE,CB,CCC,SAA,etc.
14.OEM can be available
15. BDK cable has very good sales over the world, enjoying a very good reputation based on top quality and most competitive price and best service.
Technical Data:
Product Photo:
