BS5467 STA XLPE cable
Application
STA Cable - power and auxiliary control cables for use in power networks, underground, outdoor and indoor applications and for use in cable ducting.
Standards
BS5467, IEC 60502
Conductor
Class 2 plain stranded copper
conductor to BS EN 60228:2005
(previously BS6360)
Insulation
XLPE (Cross-Linked Polyethylene)
Bedding
PVC (Polyvinyl Chloride)
Armouring
Single Core: ATA
(Aluminium Tape Armour)
Multi-Core: STA (Steel Tape Armour)
Sheath
PVC (Polyvinyl Chloride)
Sheath Colour
Black
Voltage Rating
600/1000V
Temperature Rating
0°C to +90°C
Minimum Bending Radius
1.5mm2 - 16mm2:
6 x overall diameter
25mm2 and above:
8 x overall diameter
Core Identification
1 Core: Brown
2 Cores: Brown, Blue
3 Cores: Brown, Black, Grey
4 Cores: Blue, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
Alternative core identification:
White cores with Black numbers
