drum asphalt mixing plant
1. Basic information:
1)Cold aggregate supply system:
Bin cubage: 4m3
The bin width:2.6m ;
Loading height: 2.27m;
Ring belt width:500mm;
2)Titled belt feeding conveyer
Belt width: 400mm
Motor power: 3 kW
3)Drying drum assembly
Drum diameter: 1m
Drum length: 4.5m
Motor power: 5.5kW
Driving type: chains+ gear
5)Oil burning system
Rated oil consumption:130kg/h;
Drawing fan power:3kw;
Oil pump power:1.5kw
6)Asphalt supply system
Asphalt tank volume: 10m3;
Drawing fan motor power: 4kw
2.Specification:
Model |
DHB40 |
DHB60 |
DHB80 |
DHB100 |
Output(t/h) |
≥40 |
≥60 |
≥80 |
≥100 |
Assembly total power(kw) |
74 |
90 |
100 |
120 |
Temper of the finished products(℃) |
120-160 |
|||
Fuel |
Coal/diesel |
|||
3.Attention contents
a.Because of the continuous creation and improvement on the technology and manufacturing techniques, our company has rights to change this configuration and specification before the customer choosing model and ordering, and without notifying the customer who had gotten this configuration and specification but haven’t ordered. Please consult our company before ordering. At the premise of guaranteeing the plant’s funciton and capability, some specificaiton or power maybe changed in above specificaiton with the continous improvement of the product, and we will not infrom the clients about this change again.
b.The dust collector equipped can only be applied in the area where there is no strictly restriction for the dust collector; we should choose bag dust catcher if higher environmental standard is required.
c. in view of asphalt will be solidified under low temperature, the clients are suggested to clean the asphalt pipes with diesel repeatedly after production to prevent remaining asphalts in them; asphalt pipes could be used only after being heated if there is remained asphalts in them;
4.Package & Shipment:
package:Nude package
shipment:15-20 days after got your deposit or workable LC
NOTE:PARTS OF MACHINE CAN BE CUSTOMIZED AS CUSTOMERS' REQUEST
