Home > Industrial Equipment & Components > Refrigeration Equipment > Industrial Chiller > Air Cooled Water Chiller USA Airconditioners
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Air-Cooled, r Air Cooled Chiller
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Reliable Quality Water Cooled Air Conditioner 50KW CE ApprovedNegotiableMOQ: 1 Set -
Air Cooled Screw ChillerNegotiableMOQ: 1 Set
-
High Quality Industrial Water Chiller CE ApprovedNegotiableMOQ: 1 Set
-
Made in China Air Conditioner Air Cooled ChillerUS$ 1,250 - 12,680MOQ: 1 Piece
-
Mitsubishi ChillerUS$ 930 - 13,300MOQ: 1 Set
Condition
New
Type
Other, Air-Cooled, r Air Cooled Chiller
Place of Origin
Guangdong, China
Brand Name
Hicool, HICOOL
Model Number
H-Ach45T/3
Cooling Capability(kw)
14kw
Voltage
380V
Dimension(L*W*H)
1800x890x1615mm
Weight
595KG
Certification
CE, ROHS, UL, CE
Warranty
3 years
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Air Cooled Water Chiller-Energy-efficient
-Environmental protection
-Automatic energy balance
...
Modular Air Cooled Chiller Unit
1.Air to water air conditioning system saves investment
Compared with traditional water cooled central air conditioner, air to water system does not need the whole cooling water system, nor the special machine room, can save building space greatly, save civil engineering expenditure, reduce the total project investment.
2.Classical design, easy application
Modular air cooled chiller units adopt widely acceptable modular structure design, customers can combine multiple modules to run according to different working conditions, so that the system will have high efficiency no matter under full load or partial load, meanwhile, multiple modular units can start hierarchically without big initial current shock, furthermore every module has load balance function, the units can automatically select running multiple modules or running alternately, so that the total operation life & system reserve can be improved greatly.
3.Excellent performance, stable & reliable quality
The unit adopts world famous brand scroll compressor, configured with high efficiency low noise vibration absorption fan special for air conditioner, running smoothly & silently. Water side shell and tube heat exchanger has high efficiency, good freezing-proof protection, not easy to be blocked, but easy to clean. The units all have passed strict performance matching test to insure good stability & reliability.
Application range:
Meets all kinds of industrial & commercial requirements, especially applicable to villas, hotels, hospitals, office buildings, places of entertainment, restaurants, etc.
Parameter
| Model | H-Ach45T/3 | H-Ach55T/3 | H-Ach65T/3 | H-Ach88T/3 | H-Ach108T/3 | ||
| Cooling Capacity | kW | 45 | 55 | 65 | 84 | 103 | |
| Heating Capacity | kW | 47 | 57 | 68 | 88 | 108 | |
| Rated Input Power | Cooling | kW | 13.74 | 16.67 | 22.25 | 25.81 | 34.25 |
| Heating | kW | 13.54 | 16.56 | 21.71 | 26.56 | 34.73 | |
| Rated Input Current | Cooling | A | 23 | 27 | 36 | 44 | 56 |
| Heating | A | 23 | 28 | 37 | 44 | 58 | |
| Power Supply | 3N 380V 50Hz | ||||||
| Compressor | Type | Scroll Type | |||||
| Quantity | 4 | 4 | 4 | 2 | 2 | ||
| Fan Quantity | Sets | 2 | 2 | 2 | 2 | 2 | |
| Refrigerant Charge | kg | 14 | 16 | 18 | 24 | 32 | |
| Refrigerant | R22(please inform us for R410A) | ||||||
| Ambient Temperature | -7°C~43°C | ||||||
| Control Manner | Central control and network control | ||||||
| Protection | High/low pressure protection, freezing-proof protection, over-current protection, water-break protection | ||||||
| Noise | dB(A) | 60 | 61 | 63 | 65 | 66 | |
| In/Out Water Gap Spec | DN50 | DN65 | DN65 | DN125 | DN125 | ||
| Net Dimension(LxWxH) | mm | 1800×890×1615 | 2000×1000×1800 | 2000×1000×1800 | 2160×1280×2100 | 2160×1460×2110 | |
| Net Weight | kg | 560 | 650 | 780 | 1020 | 1290 | |
| ross Weight | kg | 595 | 690 | 825 | 1080 | 1380 | |
| Note: 1) Nominal cooling conditions: condenser air inlet dry bulb temperature: 35°C, wet bulb temperature: 24°C, evaporator water inlet temperature: 12°C, water outlet temperature: 7°C 2) Nominal heatling conditions: outdoor dry bulb temperature: 7°C, wet bulb temperature: 6°C, evaporator water inlet temperature: 40°C, water outlet temperature: 45 | |||||||
.
Finished product
