ACB-002 Double Door Controller Panel Manufacturer in China

Name: ACB-002 Double Door Controller Panel Manufacturer in China
Brand: Crypton
SKU: 118604681

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

Crypton

Model Number:

ACB-002 Access Control Board control 2 door

Shenzhen Crypton Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen or HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name Crypton

Model Number ACB-002 Access Control Board control 2 door

ACB-002 Access Control Board control 2 door

I.Specifications of the Access Control Board:

A	Communication	TCP/ IP
B	Software support data base	SQL
C	Description	Control 2 door,entry&Exit by card&keypad or exit by hit button
D	Power Supply	12VDC; 4-7A
E	Power Consumption of Circuit Board	Less than 100mA
F	Input Format of Reader	Wiegand 26/34 bit (All card reader with compatible protocol, such as Motorola , HID, EM , Mifare one etc)
G	Quantity of Readers	4
H	Door Controlled	2
I	Door opening time extending setting	1-600 Seconds(adjustable)
J	Max q ' ty of controller	Unlimited

II.Technical details of the Access Control Board:

I	Operation Temperature	-40°-70°
II	Operation Humidity	10-90 % RH ,No Condensation
III	Q ' ty of users	20,000 Users
IV	Q ' ty of Event	Buffers(offline) 100,000 Event Buffers
V	Power interruption	protection measure High Speed Memory, Records never lose
VI	Max Distance	from Reader to Controller 100M (suggestion distance 80m)
VII	Max Distance	between Controllers Depand on network range
VIII	Collocations	PCB board, case, power, power line, serial port communication line, software, manual, certificate, key(2pcs), carton
VX	Alarm functions	Alarm for long time door open, ilegal break in, intimidate
X	Fire and alarm linkage	If no connection with the expansion board,,only has software interface alarm, and drive the computer speaker. If connected with expansion board, is able to alarm by hardware, if connected with strengthened expansion board, then is able to Security alarm

III.Conventional Function and all-in-one-card management and professional applications:

1	Offline operation; real time supervision; photo display	mass storage,remote unlocking
2	flexible user privilege setup;multi-user supervision;quick set	card+password unlocking
3	convenient checking and query,report exported to excel	alarm for long time unclosing
4	revisable and printable report form,unlocking at definite time	report form
5	larm for invalid card swiping,alarm for illegal break in	first card unlocking
6	nomal shift&multi-shifts time attendance management	power supply station
7	fixed ration dining management system	interface locking,interlocking
8	meeting attendance management system	intimidation alarm
9	Online patrol management &security alarm management	multi-card unlocking
10	professional users such as bank,cash house,prison	telecom station,plice station
11	integrated fire control,anti-passback and anti-tail;	emergency double locking
12	unlocking based on internal and external validation.	in door population checking

IV.Access solutions management functional schedule:

Complsive open and close door at long time	√
Open door in remote distance	√
Inter block	√
Anti pass back and tail	√
Multi-card open door	√
Open long time at specified time	√
Electronic map	√
Urgency locking	√
First card unlocking	√
Unlock based on internal and external validation	√
Keypad (card+passwor, supper password)	√
