Help CenterLT100A Medical Hospital Fixed x Ray Equipment
Related Products
-
LT100B Medical X-ray Machine PricesNegotiableMOQ: 1 Set -
LT100A 100ma Medical X-ray Machine PricesNegotiableMOQ: 1 Set
-
LT300A Hospital 300ma X-ray Machine for SaleNegotiableMOQ: 1 Set
-
LTK500 (CDG) Hot Sale 500ma X-ray Machine CostNegotiableMOQ: 1 Set
-
LTG9000 Manufacture of Medical C-arm X-ray PriceNegotiableMOQ: 1 Set
USE
General radiography,Filter-ray-filter radiograph
Unit Configuration
Control ,HT generator unit,Ht cable,X-ray tube unit,Radiographic table-X-ray source column ,Collimator
Function
The unit can used for general radiography, Bucky radiography of body’s head, chest, foot and hand, bones in lying
Feature
meter-indicating
single-table single tube
single-phase, full wave rectification
stationary anode x-ray tube assembly
X-ray tube filament s voltage regulator, space charge compensator
Radiograph plain table wimple structure and easy assembling
MIN TECHNICAL INDEXES
ITEM |
CONTENTS |
INDEX |
Demand of power supply |
Capacity |
Two-phase 30KVA |
Voltage,Frequency |
380V/220V ±10%50HZ ±0.5Hz |
|
Intemal resistance |
2Ω(380V) 0.6 Ω(220V) |
|
power supply |
Adjustable range |
380±10% at220V being adjustable continuously |
Radiograph |
Voltage |
50-90KV |
current) |
Small focus: 15mA,Big focus:30mA 60mA 100mA |
|
time |
0.04~6.35s 23grades together grading a according to R10 coefficient |
|
High-voltage generator |
Capacity |
7KVA |
Max DC output voltage |
90KV |
|
Max DC output current |
100mA |
|
X-Ray tube |
Model |
0XD4-2.9/100 |
Focus |
Small focus 1.8×1.8mm big focus4.3×4.3mm |
|
|
Radiographic table |
Length×width×height of bed surface |
2000mm×665mm×700mm |
Moving range of bed surface |
640mm in Length,200mm in breadth |
|
Ray-filter of table |
Travel in length ≥50mm |
|
Grid density N=28 | ||
Convergence distance f.=100cm | ||
Grid ratio r=8 | ||
Column of X-ray tube unit |
Moving Longitudinally along Radiographic table |
1000mm or 1800mm |
Distance to friend as moving up and down (along column) |
650~1800mm |
|
Rotary around the center of cross arm |
±180° |
|
Rotary around the shaft line of X-ray annular tubes |
-10°~60°~ +120° |
|
Max size of cassette |
356mm×432mm(14″×17″) |
|
Note: We will not make another notice if the contour of product and technical parameters will be changed
wooden box to pack LT100A medical hospital fixed x ray equipment
Weight:260Kg
Trade Term
1. This offer is valid with 30 days.
2. Delivery time: In 10 days after receive the payment
3. Item of payment: T/T ,L/C,Western Union ,Escrow ,Paypal total payment before delivery
4. Carton box
Delivery detail:
1.We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive , which is door to door ,you no need go out can get LT100A medical hospital fixed x ray equipment
2.We can also help you ship by air cargo, it takes about 2-7 days to arrive, while you need to go to Air port to take LT100A medical hospital fixed x ray equipment
3.If goods are large quantity and you need not so urgently ,you can choose by sea to save some freight cost which takes you about one month to get LT100A medical hospital fixed x ray equipment
No matter what delivery way ,depending on your actual requirements.
Who we are ?
Our Leyte Electronic Co., Limited is a leading exporter and supply chain service provider for LT100A medical hospital fixed x ray equipment
Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables.
We have exported to more than 50 countries and built long term partnerships with clients of LT100A medical hospital fixed x ray equipment
Our services:
1. For all your inquires about us or our LT100A medical hospital fixed x ray equipment , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM services. Can print your own logo on LT100A medical hospital fixed x ray equipment , can customize the retail box packing and other things.
4. We have very experienced engineers ,can help you better use LT100A medical hospital fixed x ray equipment
