USE
General radiography,Filter-ray-filter radiograph
Unit Configuration
Control, HT generator unit,Ht cable,X-ray tube unit,Radiographic table-X-ray source column ,Collimator
MAIN CHARACTERISTICS
1, Single-table/single-tube
2, Rotary anode X-ray tube unit and tangential annular tube head
3, Single-phase full wave rectification high-voltage generator
4, Power voltage(v) radiograph kilovolt (KV).step-less control electric mechanism
5, Filament stabilizer for X-ray tube unit and space charge compel mentor
6, Radiograph volume KV ,mA and S. grading and interlock protection
7, Adopt digital circuit timer. Grading according to R10 priority coefficient,(for more accurately controlling time)
8, HT primary, the zero controlled circuit of silicon-controlled rectifier of heavy power
9, Radiographic table can move in length an breadth
10,The radiographic table. Column and vibrating grid are in a whole without ceiling and floorh rails bottom
MIN TECHNICAL INDEXES
ITEM |
CONTENTS |
INDEX |
Demand of power supply |
Capacity |
Two-phase 30KVA |
Voltage,Frequency |
380V/220V ±10%50HZ ±0.5Hz |
|
Intemal resistance |
2Ω(380V) 0.6 Ω(220V) |
|
power supply |
Adjustable range |
380±10% at220V being adjustable continuously |
Radiograph |
Voltage |
50-90KV 50-90KV being adjustable continuously |
current |
Small focus:50mA100mA,Big focus:50mA 100mA 200mA 300mA |
|
time |
0.04~6.35s 23grades together grading a according to R10 coefficient |
|
High-voltage generator |
Capacity |
20KVA(instantaneous) |
Max DC output voltage |
125KV |
|
Max DC output current |
300mA |
|
X-Ray tube |
Model |
XD51.20-40/125 |
Focus |
Small focus 1×1mm big focus2×2mm |
|
Radiographic table |
Length×width×height of bed surface |
2000mm×665mm×700mm |
Moving range of bed surface |
640mm in Length,200mmin breadth |
|
Ray-filter of table |
Travel in length ≥500mm |
|
Grid density N=28 | ||
Convergence distance f.=100cm | ||
Grid ratio r=8 | ||
Column of X-ray tube unit |
Moving Longitudinally along Radiographic table |
1000mm or 1800mm |
Distance to friend as moving up and down (along column) |
650~1800mm |
|
Rotary around the center of cross arm |
±180° |
|
|
Rotary around the shaft line of X-ray annular tubes |
-10°~60°~ +120° |
|
Max size of cassette |
356mm×432mm (14″×17″) |
|
Note: We will not make another notice if the contour of product and technical parameters will be changed
wooden box to pack for LT300A hospital 300ma x-ray machine for sale
Trade Term
1. This offer is valid with 30 days.
2. Delivery time: In 10 days after receive the payment
3. Item of payment: T/T ,LC,Western Union ,Escrow ,Paypal total payment before delivery
4. Carton box
Delivery detail:
1.We ship goods by UPS/DHL/FEDEX/TNT express which is door to door ,you no need go out can get LT300A hospital 300ma x-ray machine for sale ,takes 3~ 5 days to arrive;
2.We can also help you ship LT300A hospital 300ma x-ray machine for sale by air cargo which you need to go to Air port to take LT-6200 CE fully automatic animal hematology analyzer home ,it takes about 2-7 days to arrive ;
3.If goods are large quantity and you not need LT300A hospital 300ma x-ray machine for sale so urgently ,you can choose by sea to save some freight cost which takes about one month to arrive .
No matter what delivery way ,depending on your actual requirements.
1. For all your inquires about us or our LT300A hospital 300ma x-ray machine for sale , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM services. Can print your own logo on LT300A hospital 300ma x-ray machine for sale , can customize the retail box packing and other things.
4. We have very experienced engineers ,can help you better use LT300A hospital 300ma x-ray machine for sale
Who we are ?
Our Leyte Electronic Co., Limited is a leading exporter and supply chain service provider of LT300A hospital 300ma x-ray machine for sale with more than 6 years’experience. Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables. We have exported LT300A hospital 300ma x-ray machine for sale to more than 50 countries and built long term partnerships with clients.
Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.
Where are our customers?
We have sold LT300A hospital 300ma x-ray machine for sale to more than 50 countries ,like The Democratic Republic of Congo, Saudi Arabia, Nigeria, Zambia, Angola, Egypt, Kenya, Ghana, Paraguay, Nepal and Myanmar and so on.
we like to show some of our Customers as below :
