Product Introduction:
Its clinical applications include orthopedics (arthroplasty, joint nailing, joint fluoroscopy, restoration and fixation for bone injury in emergency), radiology (abdominal organ angiography, gastrointestinal fluoroscopy), gynecology (uterus angiography), urology (kidney and bladder angiography), surgery (pacemaker implantation, peripheral vascular examination, etc.) and so on.
Key Features
- Adopts the true digital high frequency host, gets the clearest and richest image with minimum dose, greatly reduces the potential harm of x-ray to clinicians and patients.
- The unique double displays make operation intuitive, easy and reliable.
- The vertical and horizontal movements and rotation of C-arm are all electric maneuvered
- Micro-computer based controller features with failure self-diagnostic function, easy maintenance.
- Digital interfaces optionally equip with picture collection & storage workstation, directly upgrade the digital image system, to provide a short cut for your heavy file management.
Upgraded Digital Image System
l Up to 100,000 static images stored in hard disk
l Multi-image simultaneously display
l Image processing functions: rotation, overturn lightness and contrast adjustment
l Diagnostic report by laser printer
Technical Data:
Generator power/Frequency |
3.5kw/40KHz |
5kw/40KHz |
Radiography KV |
40-110KV |
40-120KV |
Radiography mA |
30-70mA |
24-70mA |
Fluoroscopy KV |
40-110KV |
40-120KV |
Fluoroscopy mA |
0.1-5mA |
0.1-5mA |
Pulse fluoroscopy |
0.1-8mA |
0.1-8mA |
Focus size |
0.6×1.5mm |
0.3×0.6mm |
Stationary anode |
Rotation anode |
|
Anode heat capacity |
30KJ(40kHU) |
150KJ(200kHU) |
Heat capacity of |
500KJ(667kHU) |
600KJ(800kHU) |
Collimator |
Iris, auto-tracking, variable visual field, double leaf |
|
Focus-to-image intensifier distance(SID) |
1000mm |
1000mm |
C-arm depth |
730mm |
730mm |
C-arm open |
815mm |
815mm |
C-arm arc glide with full balance |
115° |
115° |
C-arm rotation(motored) |
±180° |
±180° |
Upward and downward movement(motored) |
400mm |
400mm |
Forward and backward movement(motored) |
200mm |
200mm |
Horizontal swing angle |
±12.5° |
±12.5° |
Image intensifier |
9" metal screen intensifier |
|
Camera |
High speed CCD camera |
|
Monitor |
14" high resolution monitor |
|
Panel |
Two operation panels, automatic display error codes |
|
Image memory |
Store 8 images, freeze the last image, multilevel denoise, double displays in one screen |
|
Supply power |
220V,50Hz,20A |
|
Power capacitor |
4KVA |
|
wooden box to pack for LTG9000 manufacture of medical c-arm x-ray price
Trade Term
1. This offer is valid with 30 days.
2. Delivery time: In 10 days after receive the payment
3. Item of payment: T/T ,LC,Western Union ,Escrow ,Paypal total payment before delivery
4. Carton box
Delivery detail:
1.We ship goods by UPS/DHL/FEDEX/TNT express which is door to door ,you no need go out can get LTG9000 manufacture of medical c-arm x-ray price ,takes 3~ 5 days to arrive;
2.We can also help you ship LTG9000 manufacture of medical c-arm x-ray price by air cargo which you need to go to Air port to take LT-6200 CE fully automatic animal hematology analyzer home ,it takes about 2-7 days to arrive ;
3.If goods are large quantity and you not need LTG9000 manufacture of medical c-arm x-ray price so urgently ,you can choose by sea to save some freight cost which takes about one month to arrive .
No matter what delivery way ,depending on your actual requirements.
1. For all your inquires about us or our LTG9000 manufacture of medical c-arm x-ray price , we will reply you in detail within 24 hours
2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM services. Can print your own logo on LTG9000 manufacture of medical c-arm x-ray price , can customize the retail box packing and other things.
4. We have very experienced engineers ,can help you better use LTG9000 manufacture of medical c-arm x-ray price
Who we are ?
Our Leyte Electronic Co., Limited is a leading exporter and supply chain service provider of LTG9000 manufacture of medical c-arm x-ray price with more than 6 years’experience. Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables. We have exported LTG9000 manufacture of medical c-arm x-ray price to more than 50 countries and built long term partnerships with clients.
Your satisfaction is our duty! It will be our great honor to serve you. We do hope we can offer you more help in medical field and build the long term business relationship with you.
Where are our customers?
We have sold LTG9000 manufacture of medical c-arm x-ray price to more than 50 countries ,like The Democratic Republic of Congo, Saudi Arabia, Nigeria, Zambia, Angola, Egypt, Kenya, Ghana, Paraguay, Nepal and Myanmar and so on.
we like to show some of our Customers as below :
