USE
General radiography,Filter-ray device radiography
Unit Configuration
Control,HT generator unit,Ht cable,X-ray tube uni,Diagnostic table,Collimator
MAIN CHARACTERIDTICS
1, Single table and single tube
2, Design according to the electric mechanism of middle-size machine, the function is reasonable function.
3, High-voltage system is of split structure, with high-voltage generator of full-wave rectification and stable operation
4, Supply voltage (V), photograph kilovolt (kV) and infinitely variable control.
5, Equipped with the manostat for filament of X-ray tube and the spacecharge compensator as to ensure the stable and accurate output
6, Equipped with the capacity limitation and portection circuit and Kv mA S interlock limit protection
7, The timer circuit grade according to R10 priority coefficient and an exact time control
8, The photographic flat bed has a vibrating ray-filter
9,The pillar has only the bottom trick, with easy installation.
MIN TECHNICAL INDEXES
Supply power |
Voltage |
220V/380V±10%(single phase ) |
||||
Frequency |
50Hz±0.5Hz |
|||||
Capacity |
10KVA |
|||||
Intemal resistance |
380v:2Ω,220V:0.6Ω(2Ωat80v; 06Ωat220V) |
|||||
Max DC output voltage |
90KV |
|||||
Max DC output current |
125mA |
|||||
Radiograph |
Voltage |
50-90KV |
||||
current |
Small focus 15mA , big focus30mA 60mA 100mA |
|||||
time |
0.04-6.3s,24grades together |
|||||
High-voltage generator |
Capacity |
7KVA |
||||
X-Ray tube |
Model |
XD4-2.9/100 |
||||
Focus |
Small focus 1.8mm big focus4.3mm |
|||||
Radiograph table |
Bed face (L×W×H) |
1960×660mm×700mm |
||||
Bucky |
Grid density N28 |
|||||
Convergence distance fo 100cm | ||||||
Grid ratio r8 | ||||||
Max size of cassette |
356mm×432mm(14″×17″) |
|||||
Pollar of X-ray source unit |
Moving in length (along The bottom table ) |
1350mm |
||||
moving un breath |
360mm |
|||||
moving up and down |
720~1800mm |
|||||
MAX VOLUME OF RADIOGRAPH | ||||||
Focus of X-Ray tube |
Radiograph mA |
Max Radiograph KV |
Max exposure time allow |
|||
Small focus |
15mA |
90KV |
6.3S |
|||
Large focus |
30mA |
90KV |
6.3S |
|||
60mA |
90KV |
6.3S |
||||
100mA |
85KV |
2.5S |
||||
Note: We will not make another notice if the contour of product and technical parameters will be changed
wooden box to pack LT100B Medical x-ray machine prices
Trade Term
1. This offer is valid with 30 days.
2. Delivery time: In 10 days after receive the payment
3. Item of payment: T/T ,LC,Western Union ,Escrow ,Paypal total payment before delivery
4. Carton box
Delivery detail:
1.We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive , which is door to door ,you no need go out can get LT100B Medical x-ray machine prices
2.We can also help you ship LT100B Medical x-ray machine prices by air cargo which you need to go to Air port to take LT100B Medical x-ray machine prices home ,it takes about 2-7 days to arrive ;
3.If goods are large quantity and you not need LT100B Medical x-ray machine prices so urgently ,you can choose by sea to save some freight cost which takes about one month to arrive .
No matter what delivery way ,depending on your actual requirements.
