Stocks for USB WiFi antenna Ralink RT5370 IEEE 802.11 b/g/n 150 Mbps USB WiFi adaptor Ralink RT-5370

FOB Price

Negotiable / Piece

20 Pieces(Min.Order)

Supply Ability 30000 Piece / Pieces per Month
Port Shenzhen
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	JC-4T
Model Number	JC-4T

Product Description

This mini WLAN adapter with rotable antenna supporting IEEE 802.11 b/g/n

1.Scope

The JC-4T is a highly integrated MAC/BBP and 2.4GHz RF/PA/LNA single chip with 150Mbps PHY rate supporting. It fully complies with IEEE802.11n and IEEE802.11b/g&0.1180.89 Safari/537.1 Content-bsp;wireless connectivity at high standards, delivers reliable, cost-effective, throughput form an extended distance. The JC-4T is designed to support standard based features in the areas of security, quality of service and international regulation, giving end users the greatest performance anytime in any circumstance.The very small and compact WLAN adapter design is good for wireless connectivity when an external antenna needs

2.Features

l802.11b:1,2,5.5,11Mbps

l802.11g:6,9,12,18,24,36,48,54Mbps

802.11n: (20MHz) MCS0-7, Support up to 72Mbps (40MHz) MCS0-7,Support up to 150Mbps OFDM, Peak rate 150Mbps, Peak throughput 90Mbps

Security support for 64/128 WEP,WPA,WPA2,TKIP,AES

Operates in 2.4GHz frequency bands.Power Management

Hardware
Main Chipset	Ralink RT5370
Host interface	USB 2.0/1.1 Type A
LED	Link/ Activity
RF Performance
Standards	IEEE802.11b/g & 802.11n (1T1R mode, 150Mbps)
Antenna	2dBi undetachable antenna
Operation Frequency	2412~2483.5 MHz (varies according to different regions)
Typical Tx Power (E.R.I.P)	802.11b (CCK)11Mbps19+/-1dBm; 802.11g (OFDM) 54Mbps 16+/-1dBm
Typical Tx Power (E.R.I.P)	802.11n (HT20@MCS7), 15+/-1dBm; 802.11n (HT40@MCS7)15+/-1dBm
Receive Sensitivity	802.11b: -86+/-1dBm; 802.11g: -74+/-1dBm
Receive Sensitivity	802.11n (HT20) -70+/-1dBm; 802.11n (HT40)-70+/-1dBm
Software Support
Operation System	WindowsCE/2000/XP/Vista/7;Linux 2.6.X;Mac OS X
Security	WEP 64/128bit ,WPA,WPA2,802.1x,and 802.11i,Cisco CCS Compliant
