Main technical parameters:
| Basic parameters: | |
| Train marshalling | 6-car train |
| Power supply | Elevated catenary DC1500V |
| Passenger capacity: | |
| Seating area | 334 passenger/train |
| Fixed passenger capacity AW2(6p/m^2) | 1860 passenger/train |
| Passenger capacity AW3(9p/m^2) | 2462 passenger/train |
| Dynamic performance: | |
| Construction speed | 90km/h |
| Max running speed | 80km/h |
| Stability index: | |
| Jerk limit | 0.75m/s^2 |
| Mean initial acceleration(0-35km/h) | ≥1.0m/s^2 |
| Mean service brake deceleration(80km/h-0) | 1.0m/s^2 |
| Mean emergency brake deceleration(80km/h-0) | ≥1.3m/s^2 |
| Air condition: | |
| Refrigeration ability per unit | ≥ 42kw |
| carbody inner temperature | 27°C |
| carbody inner relative humildity | <65 °C |
| Car dimension: | |
| Car Material | aluminium alloy |
| Total train length | 140000mm |
| Carbody length (Tc) | 24400mm |
| Carbody length (Mp/M) | 22800mm |
| Carbody height | 3800mm |
| Max. carbody width | 3000mm |
| Height from floor to top rail | 1130mm |
| Height from coupler center line to top rail | 720mm |
| Distance between bogie centers | 15700mm |
