Help CenterLow-Floor Tram Vehicle
Related Products
Specifications
This car can run on the street of City by rail track, with good dynamic performance and comfortable design.Main technical parameters:
| Basic Parameters | |
| Carbody length | 32230mm |
| Carbody width | 2650mm |
| Carbody height | |
| Height from Roof to Top Rail(New Wheel, Pantograph Down) | ≤3600mm |
| Inner Height of Passenger Saloon(Floor to Inner Ceiling Center Line) | 2102-2225mm |
| Height of Standing Area in Passenger Saloon | ≥1900mm |
| Height from Floor to Top Rail at Entrance (New Wheel, AW0) | 330mm |
| Wheel-Base | 1850mm |
| Wheel Diameter:New Wheel | 620mm |
| Max. Wom Wheel | 540mm |
| Coupler Height (Height from Coupler Center Line to Top Rail) | 430mm |
| Gang Way | |
| Width | 1500mm |
| Height | 2132-2193mm |
| Tractive Performance | |
| 1.For AW2 load, half worn wheels, on dry, straight rail and under rated voltage condition, traction performance are: | |
| 1) Max. Continuous Running Speed | 70km/h |
| 2) Designed Structure Speed | ≥80km/h |
| 3) Initial Acceleration(0-40km/h) | ≥1.13m/s² |
| 4) Mean Acceleration(0-70km/h) | ≥0.71m/s² |
| 2. Washing Speed | 3km/h |
| 3. Reverse Speed | 10km/h |
| Braking Performance | |
| The braking performance should meet the requirements of EN13452-1, as well as the following requirements. | |
| 1.Mean Service Braking Deceleration(70km/h~0 including response time) | ≥1.2m/s² |
| 2.Mean Safety Braking Deceleration(70km/h~0 including response time) | ≥1.5m/s² |
| 3.Mean Emergency Braking Deceleration(70km/h~0 excluding response time) | ≥2.8m/s² |
| 4.Mean Service Braking Jerk Limit | ≤1.5m/s³ |
These products may interest you:
Why to choose us? that is:
1.Brand: We are subsidiary of CSR, which is a big group called "China South Railway".
2.Experience & Profession: Our parent company is an enterprise specialized in research and manufacture of rail transport equipment in China, and is the first-class large-scale company in China’s railway equipment manufacturing industry. It has a history of more than 100 years in the railway vehicle field and its products sold to 18 railway bureaus and local railways.
3."To we" is your best choice: What does "to we" means? It means you will get two "V" products, versatile and various.
• Versatile products that suitable for different conditions of clients. In order to ensure the products performing well in local conditions, We could redesign and manufacture products according to basic needs of clients.
• Various products, different railway transit products, including EMU&DMU, passenger coach, metro, light rail, trolley, locomotives and some related products.
4.High quality after-sale service: We will provide professional technical worker to local car depot for vehicle maintenance. In another aspect, if you need, we are also a professional agency of car depot equipment. Generally speaking, we could provide an integration service.
Fast channel to our workshop:
If you have interest in our products & want to know more about our company.
Here is our company home page: www.csrhz.en.china.cn
Please contact us once you get any problem.
Mob: +86-13705880033
Skype: hznc2013
