SC767B T125 Vehicle Rocker Switch, Double Pole,1E4/5E4, UL Approved

Name: SC767B T125 Vehicle Rocker Switch, Double Pole,1E4/5E4, UL Approved
Brand: BAOKEZHEN
SKU: 118128657

Negotiable MOQ: 20000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

BAOKEZHEN

Model Number:

SC767B t125 rocker switch

Shenzhen Baokezhen Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or other Guangdong port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name BAOKEZHEN

Model Number SC767B t125 rocker switch

Max. Current 16A

Max. Voltage 125VAC/250VAC

Mechanical Life 5E4

Product Description

SC767B t125 1E4/5E4 rocker switch double pole rocker switch Vehicle rocker switch UL rocker switch BAOKEZHEN brand rocker switch

P/N	SC767B t125 Vehicle rocker switch, double pole
Current & Voltage	15(3)A 250VAC 1E4 T125/55 15A 125/250VAC
Life	1E4/5E4
Materials	Housing & Button-PA /PC Terminals-copper Alloy, Contacts-Ag / AgcdO
Contact gap	more than 3mm
Contact resistance	20 mΩ or less than 20 mΩ
Insulation resistance	more than 100 mΩ
High voltage resistance	750V
Resistance to tracking	PTI 175
Protection type	IP20
Ambient temperature	0℃,+125℃
Flammability	UL94V-0
Heat and fire temperature	850℃
Approvals	UL & SEMKO
These switches are suitable for appliances of protection class II, such as oven, coffee machine, stirrer, vehicle and so on. For more switches, pls refer to .
