Specifications
PET waste bottle recycling lineHigh automation
Perfect synchronized
Customized process solutions
Overview
To separate PET bottles to flakes from PE/ PP label, cap, oil, garbage, protect the environment, avoid white pollution.
Recycled PET can be used again to produce PET-based plastic products, e.g. bottles (not food & beverage-grade), fiber/cloth, sheet, strap band and, etc.
Range Available:
Input capacity | 500kg/h | 1000 kg/h | 2000 kg/h |
Workshop(M*M*M) | 42 (L)×10(W)×6(H) | 55(L)×15(W)×6(H) | 70(L)×18(W)×6(H) |
Manpower | 6 Persons | 8 Persons | 12 Persons |
Installation power | 156KW | 307KW | 420KW |
Water Consumption: | 2 Ton/h | 3.5 Ton/h | 5 Ton/h |
Features:
- The whole line is fully automatic and it has characteristics of high efficiency, low noise and easy operation.
- The line can easily wash and recycle waste PET bottle flakes ,which includes PE/PP labels, PVC labels, paper labels, HDPE cups, glue, mud, beverage leftover, oil, and scrap iron.
- It adopts hot water washing to get good quality. Various output capacities can be chosen: 500kg/h, 1000kg/h, and 2000kg/h(Customized).
- The degree of cleaning is as much as 96% and the degree of drying is as much as 98%.
Main List And Function:
No. | Item | Qty | Remark |
1 | Bale Breaker | 1 Set | Cut And Break Packaged PET Bottles |
2 | Belt Conveyor | 1 Set | Conveying Bottles |
3 | Screening Machine | 1set | Filtering Sand, Dirty, Impurity |
4 | Belt Conveyor | 1set | Conveying Bottles |
5 | Label Remover | 1 Set | Removing Label From Surface Of Bottle Label Removing Efficiency: 90%-95% |
6 | Manual Sorting Table | 1 Set | Sorting Different Plastics By Manually |
7 | Metal Detector | 1set | Detecting Metal, Aluminum, Stainless Steel And So On Automatically |
8 | Belt Conveyer | 1 Set | Conveying Bottles |
9 | Wet Crusher | 1 Set | With Water, The Material Of The Blade Adopt Skd-Ii Or 9crsi |
10 | Screw Feeder | 1 Set | Conveying Flakes |
11 | Twin Screw Floating Washer | 1 Set | Washing And Separate PP Caps/Label According To Different Specific Gravity |
12 | Screw Feeder | 1 Set | Conveying Flakes |
13 | Hot Steam Washer | 1 Set | Removing Oil By NAOH And Hot Washer Or Hot Steam |
14 | Screw Feeder | 1 Set | Conveying Flakes |
15 | Friction Washer | 1 Set | High Friction Efficiency By High Speed, Adopt Germany Technology |
16 | Twin Screw Floating Washer | 1 Set | Washing And Separate PP Caps/Label According To Different Specific Gravity |
17 | Dewatering Machine | 1 Set | High Dewatering Efficiency By High Speed, Adopt Germany Technology, Water Content 5% |
18 | Label Separator | 1set | Separating Leftover Label From Pet Flakes |
19 | Drying System And Storage Hopper | 1 Set | Drying By Electric, Water Content ≤2% |
20 | Electrical Control Cabinet | 1 Set | Adopts ABB , SIEMENS And OMRON As Main Electric Component. |
