Specifications
XinTai Gravure Poly Bag Printing Machine1.High Speed,120m/min
2. High effiency
3.Reasonbale design.
XinTai Gravure Poly Bag Printing Machine
Printing Material
PVDC |
35-60micron |
PET |
12-60micron |
OPP |
20-60micron |
BOPP |
20-60micron |
PE |
30-100micron |
Nylon |
12-50micron |
CPP |
20-60micron |
Composite film |
15-60micron |
Cellophane |
20-30micron |
PVC |
32-60micron |
Paper |
30-80gsm |
|
|
Main Technical Parameters
Main parameter | |
Direction |
From left to right |
Printing color |
8 color |
Max width |
1100mm |
Max machine speed |
150m/min (Φ170mm Cylinder) |
Max printing speed |
1120m/min (Φ170mm Cylinder) |
Diameter of printing cylinder |
Φ120mm-Φ300mm |
Precision of register |
Lengthwise ±0.15mm (Auto register tracking) |
Cross direction ±0.15mm (Manual register tracking) | |
Unwinding diameter |
Φ600mm |
Shaft |
Air shaft |
Paper core diameter |
3" or 6" |
Tension |
3-30Kg |
Precision of tension |
±0.5Kg |
Air supply |
0.6Mpa |
Pressing force |
800kg |
Doctor blade swing capacity |
±5mm |
Heat way |
Electricity |
Main motor power |
15kw |
Main power |
95kw |
Dimension |
13000×2200×2800(mm)
|
Weight |
15000kg
|
Shipment
Product printed
Advantage & services
1. One Year warranty.
2. Our engineers available to service machinery overseas.
Contact information
XinTai Printing Machinery Co., Ltd.
Tel: 86-577-65150111 65150222
Fax: 86-577-65161177
Thank you for your time and looking forward to our cooperation!
