Specifications
Structure:1. Integral high strength low stress alloy cast iron wallboard
2. Guide roller install: two shaft hold
Printing material
80-280gsm paper
Main parameter | |
Direction |
From left to right |
Printing color |
8 color |
Max width |
850mm |
Max machine speed |
100m/min(Φ200mm) |
Max printing speed |
80m/min(Φ200mm) |
Diameter of printing cylinder |
Φ120mm-Φ300mm |
Precision of register |
Lengthwise ±0.2mm (Auto register tracking) |
Cross direction ±0.2mm (Manual control) | |
Unwinding diameter |
Φ1500mm |
Paper collect way |
Web material (Printing surface outside) |
Shaft |
Air shaft |
Paper core diameter |
3" or 6" |
Tension |
20-60Kg |
Precision of tension |
±0.5Kg |
Air supply |
0.8Mpa |
Pressing force |
2500kg |
Doctor blade swing capacity |
±5mm |
Heat way |
Electricity / Steam (Customer build) |
Water cooling pressure |
2-3kg/cm2, 18-20°C |
Main motor power |
22kw |
Main power |
210kw (Electric heating) 130kw (Steam heating) |
