Help CenterTM-1939 for Gaming Kiosks Compatible ELO SAW Touch Open Frame Touch Monitor
Related Products
-
LeadingTouch 55" Multitouch Open Frame Touch Touch Monitor TM-5558US$ 1,000 - 2,000MOQ: 1 Unit -
LeadingTouch 42" Multitouch Open Frame Touch Monitor TM-4258US$ 1,000 - 1,200MOQ: 1 Unit
-
Leadingtouch Touch Monitor for Kiosks 15"-26"US$ 180 - 1,000MOQ: 1 Unit
-
LeadingTouch Kiosks Open Frame Touch Monitor 15",17",19",22"US$ 150 - 400MOQ: 1 Unit
-
LeadingTouch 42" Multitouch Open Frame IR Touch Monitor TM-4258US$ 850 - 1,200MOQ: 1 Unit
Specifications
19inch open frame touch monitor1. SAW dustproof, waterproof touch Frame
2, Dual RS232 and USB touch input
3, compatible ELO
TM-1939 is 19inch open frame touch monitor, SAW touch solution (more option is same structure with different touch solution)
LeadingTouch Technology Co.,Ltd. is professional manufacture of touch screen and touch monitor.
Leadingtouch touchscreens, controllers, and cables have been approved for CE marking. Where appropriate, Touchmonitors are marked CE compliant, and are typically Class B. Systems incorporating leadingtouch touchscreens, controllers, and cables have been approved to FCC Class A compliance. Touchmonitors typically are FCC Class B verified RoHS
| Model | TM-1939 |
| Description | 19″TFT Rear Mount Touchmonitor |
| Case/Bezel Color | Black |
| Display | 4:3 Ratio Active matrix TFT LCD |
| Optimal(native) resolution | 1280X1024@60Hz |
| Sychronization Range | Horizontal:30-80 kHz; Vertical: 60-75Hz |
| Useful screen area | Horizontal: 14.8" (376 mm);Vertical: 11.85" (301mm) |
| Colors | 16.7 million |
| Brightness | LCD panel: 300cd/m2 (typical) |
| with touchscreen: 230 cd/m2 (typical) | |
| With SAW touchscreen: 280 cd/m2 (typical) | |
| Pixel Pitch | 0.294 x 0.294 mm |
| Response Time | 8 msec (typical) |
| Contrast ratio | 800:1 typical |
| Viewing angle(typical, from center) | Horizontal (left/right): 160°(80° /80° ) |
| Vertical (up/down): 170°(85° /85° ) | |
| Backlight Lamp life | 50,000 Hrs to 1/2 brightness |
| Input video format | VGA or DVI optional |
| Input video signal connector | Mini D-Sub 15-Pin VGA type |
| On Screen Display(OSD) | Remote OSD with 1.2m cable |
| Touch Technology | SAW(Resistive, Capacitive Optional) |
| Touch Interface | Combo 10ms232 and USB interface |
| Touch Resistive Time | 10ms |
| Mounting Options | Rear mount VESA, 75 mm & 100mm |
| Power supply | External:100-240V AC, 50-60 Hz |
| Power Consumption | 50W max |
| Temperature Range | Operating: 0°C to 50°C; Storage: -20°C to 60°C |
| Humidity Range | Operating: 10%-90%; Storage: 5%-90% no condensing |
| Touchmonitor Dimension | 415x 343x 50(mm) |
| Shipping Carton Dimension | 515x 450 x 175(mm) |
| Weight(approx.) | Monitor: 4.6kg / shipping: 7kg |
| Warranty | Monitor: 3 years/’; LCD Panel: 1 year |
| Agency Approvals | FCC, CE, RoHS compliant |
The Touch Monitor will be packaged into the carton, option as below
Option one
one carton is for one touch monitor
dimension: 53 x 44 x 22cm
gross weight: 10KGS
Option two
one carton is for 3 touch monitor
dimesnion:50 x 28 x 50cm
gross weight: 18.5KGS
LeadingTouch own strong design and produce abality.
supply good product, before/ after sales service, perfect quality control and engineer team never and will not disappoint customers forever.
Welcome to Enjoy LeadingTouch Family
LeadingTouch will be your best choice, I am awaiting for you and welcome you here.
