Home > Computer Products > Mainboard > Special 3.5 Inch Fanless ATOM N2600 CPU Car IPC Mini HD Computer Motherboard Dual Network
Special 3.5 Inch Fanless ATOM N2600 CPU Car IPC Mini HD Computer Motherboard Dual Network
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Brand Name:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ITX ATOM/D2700/D2560 With GT520 Ultra Thin Support WIFI/SSD/2VGA HDMIUS$ 1 - 2MOQ: 1 Piece -
Atom N270 LVDS 3.5 Inch Fanless Industrial Motherboard Industry Motherboard ITX MINI MotherboardUS$ 1 - 2MOQ: 1 Piece
-
Atom D525 Industrial Panel Computer Motherboard / Medical Equipment / Car Motherboard / 3.5 Inch D525 MotherboardUS$ 1 - 2MOQ: 1 Piece
-
Intel ATOM D525 D525 Multi-Lan Firewall Motherboard Soft RouteUS$ 1 - 2MOQ: 1 Piece
-
ITX-N29_18 12*12 With Baytrail Motherboard, Dual Lan Quad Core Mainboard J1800,J1800 Nano Itx Motherboard OEMNegotiableMOQ: 2 Pieces
Products Status
Stock
Application
Desktop
Brand Name
Other
Model Number
N2600
Specifications
Special 3.5 inch fanless ATOM N2600 CPU car IPC Mini HD computer motherboard dual networkSpecial 3.5 inch fanless ATOM N2600 CPU car IPC Mini HD computer motherboard dual network
onboard Intel atom N2600 processor dual-core
Intel NM10 Express Chipset.
support a DDR SO DIMM III memory, maximum support 2GB (N2600 supports 2GB)
support VGA, HDMI, LVDS synchronous / asynchronous display.
integrated two RTL8111E Gigabit LAN.
6 RS232 interface (COM2 support 232,422,485 mode).
to support two the MINI-PCIEx1 slot can use the SSD / wireless card.
Long 14.8CM wide 10.2CM
Introduce the N2600
Dual-core Atom N2600 using 32-nanometer process, 1.6GHz clock speed, integrated HD3600 graphics card, frequency upgrade to 400MHz, supports 2GB of memory. New N2600 can achieve playback of 720p and 1080p resolution and low calorific value, performance processor Z670 twice that of the previous generation, especially graphics performance significantly.
EPIC-N26 VER: 2.1
Size
3.5 "SBC 6layers; PCBsize: 14.8x10.2cm
Chipset
Intel ® NM10 Express Chipset
Central processor
Intel Atom N2600 processor dual-core
Memory
1 * 204-pin DDR3 1066/800MHz memory, up to 2GB (N2600 supports 2GB)
Expansion Slots
2 * Mini-PCIE x2 (SSD / Wireless LAN support)
Audio features
Realtek ALC662 6-channel high-fidelity audio
Storage capabilities
1 * SATAII hard disk interface
1 * MiniSATA slot (supports SSD drives)
Network functions
Integrated RTL8111E network chip supports 10/100/1000Mbps Ethernet data transmission, supports Wake on LAN feature
Backplane I / O interface
1 * 12VDC_JACK input interface
2 * USB2.0 interface
2 * RJ-45 network interface
1 * AUDIO interface (Line out)
1 * HDMI Interface
1 * VGA interface
Built-in I / O interface
1 * PWROUT (hard drive power connector)
1 * KB2 interface
4 * USB 2.0 interface
6 * COM port (COM2 support the RS232/RS422/RS485 mode)
1 * Audio Connector (2 * 5 pumping 8)
1 * TX-RXCOM (RS422/485 interface)
1 * CPUFAN interface
1 * FP1 (2 * 5pin front panel switch button and indicator Interface)
1 * LVDS and LVDS INVERTER
1 * VGA 2 * 5pin interface
1 * SW3 DIP switch 1 * CIR interface
Display function
Integrated Intel GMA3650 graphics (shared memory 128/224MB)
Support HDMI, VGA, LVDS, synchronous / asynchronous display
LVDS support the single 24bit and dual-channel 24bit, LVDS screen when
To choose its resolution according to the the LVDS screen resolution SW3 DIP switch
BIOS
AMI 16MB Flash ROM
Watchdog
Supports hardware reset function (256, 0 to 255 seconds)
The type of power source
DC12V input
Operating Humidity
0-95% relative humidity, non-condensing
