Heavy Duty Apron Feeder

Heavy Duty Apron Feeder thumbnail-1
Heavy Duty Apron Feeder thumbnail-2
Heavy Duty Apron Feeder thumbnail-3
Heavy Duty Apron Feeder photo-1
Heavy Duty Apron Feeder photo-2
Heavy Duty Apron Feeder photo-3
US$ 1 - 10,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Stone or Ore
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Hainan Pengsheng Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Heavy Duty Apron Feeder
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Stone or Ore
Power Type Diesel
Capacity(t/h) 100m3/h
Place of Origin Zhejiang, China
Brand Name GBZ120-5.6
Model Number GBZ120-5.6
Power(W) 15kw
Dimension(L*W*H) 8183*5228*2080
Weight 5.35t
Certification ISO9001:2000,CE,SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

1.Quick Detail of our Heavy Duty Apron Feeder



Condition:

New

Application:

Mining

Capacity(t/h):

128~280

Place of Origin:

Zhejiang, China (Mainland)

Model Number:

GBZ120-5.6 Vibrating Feeder

Power(W):

15kW

Weight:

5.35t

Certification:

ISO9001

After-sales Service Provided:

Engineers available to service machinery overseas

Standard::

Export Standard

Transportation::

Sea Freight

Certificate::

ISO9001:2000,CE,SGS

Application::

Stone or Ore







2.More info. of our   Heavy Duty Apron Feeder

 A:Application



Heavy plate feeder(Apron Feeder)is a kind of linear direction feeding equipment. It features smooth vibrating, reliable operation, long service life and being suitable for feeding. Vibrating feeders are widely used in mining, building-material, silicate andchemical industry in the crushing and screening plants.In the Sand-Stone production line, vibrating feeder can send materials to crusherevenly and continuously and at the same time, it can screen materials roughly.Vibrating feeder can be used in these areas such as metallurgical industry, coal mining industry, mining-selecting, building, chemical and grinding industry, etc.



 B:working principle of heavy plate feeder apron feeder



Heavy plate feeder(Apron feeder)consists of vibrating frame, spring, vibrator, motor vibrating device and motor. The vibrator is made of two fixed eccentric shafts whose gearsare jogged. When installation, the two gears must be jogged according to the sign. Through drive of the motor, the two eccentric shafts start rotating to producea linear huge power which forces the feeder to vibrate. Through the vibration,the materials will slip and sling on the funnel, moving forward, when the materialspass the screening part, smaller parts will fall down, and avoiding the furthercrushing, so screening purpose can be reached.



3. Technical dates of heavy plate feeder apron feeder





Model Chain Plate Chain Plate Chain Plate Feed Particle Size(mm) Capacity(m3/h) Power(kw) Dimensions(LΧWΧH) Weight(kg)
   width(mm) center distance of chain wheel(mm)  speed(m/s)
GBZ120-4.5 1200 4500 0.05 ≤500 100 15 6983χ5228χ2080 31279
GBZ120-5 1200 5000 0.05 ≤500 100 15 7593χ5228χ2080 33427
GBZ120-5.6 1200 5600 0.05 ≤500 100 15 8183χ5228χ2080 34321
GBZ120-6 1200 6000 0.05 ≤500 100 15 8638χ5228χ2080 35900
GBZ120-8 1200 8000 0.05 ≤500 100 22 10533χ5293χ2080 41342
GBZ120-8.7 1200 8700 0.05 ≤500 100 22 11383χ5293χ2080 43164
GBZ120-10 1200 10000 0.05 ≤500 100 22 12583χ5293χ2080 46962
GBZ120-12 1200 12000 0.05 ≤500 100 22 14653χ5293χ2080 61844
GBZ120-15 1200 15000 0.05 ≤500 100 30 17658χ5518χ2080 62157
GBZ150-4 1500 4000 0.05 ≤600 150 15 6613χ5528χ2080 33197
GBZ150-6 1500 6000 0.05 ≤600 150 22 8638χ5593χ2080 39257
