Specifications
hydac water filter element1.Material:PP/stainless steel ect.
2 Timely delivery
3 Manufacturer, factory
20 micron hydac water filter elements
hydac water filter element pictures
Hydac Water Filter Element Introduction
The Ultipleat High Flow filter is suited for applications such as cooling water, pre-RO, and resin trap filtration.
It is a large diameter, coreless, single open-ended, pleated cartridge with an inside to outside flow pattern.
The filters patented crescentshaped pleat geometry, combined with its large 6"/ 152 mm diameter, reduces the
number of filters and size of housing required. The cartridge is also available in a wide range of Pall media types for
other applications.
Hydac Water Filter Element Benefits
· Up to 50% smaller filter system possible
· Up to forty times fewer elements to change out
· Very high flow rates per filter cartridge, up to 500 gpm / 114 m3/hr
· Available in 20"/ 508 mm, 40" / 1016 mm and 60" / 1524 mm lengths
· Coreless construction to minimize waste disposal
· Absolute rated filter medium for reproducible performance
· Inside to outside flow configuration - all contaminants held within the single open ended filter
Materials of Construction
· Filter Medium:
Pleated polypropylene depth structure
· Support/Drainage:
Polypropylene
· Endcaps:
Glass filled polypropylene
· O-ring:
Ethylene propylene
Hydac Water Filter Element Removal Ratings
· 3.2 µm, 4.5 µm, 10 µm, 20 µm, 40 µm, 70 µm, 100 µm
Hydac Water Filter Element Configuration
· Single open end, 6" / 152 mm diameter filter
Hydac Water Filter Element Operating Conditions
· Maximum Operating Temperature:
180°F / 82°C
· Maximum Differential Pressure1(nominal inside to outside flow):
50 psid at 180°F / 3.4 bar at 82°C
Model and Size
Name |
Model |
Length |
Filtr. |
0D |
Temperature |
Flow (L/min) |
Press. |
Loss Pressure (Mpa) |
|
Initial |
Max |
||||||||
Big flow |
XLDM-20×* |
20 |
1~70 |
6 |
70 |
632 |
20°C:0.34 |
≤0.08 |
0.25 |
XLDM-40×* |
1260 |
||||||||
XLDM-60×* |
1890 |
||||||||
Name |
Model |
Length |
Filtr. |
0D |
ID |
Temperature |
Press. |
Loss pressure (Mpa) |
|
Initial |
Max |
||||||||
Melt&spurts |
RP-L×micron |
5~60 |
1~50 |
φ60 |
φ28 |
≤60 |
0.5 |
≤0.02 |
0.2 |
Name |
Model |
Length |
Filtr. |
0D |
ID |
Temperature |
Press. |
Loss pressure(Mpa) |
|
Initial |
Max |
||||||||
Yarn-wound |
CR-L×micron |
5~60 |
1~50 |
φ60 |
φ28 |
≤70 or ≤90 |
0.5 |
≤0.02 |
0.2 |
