Specifications
water filter element1 Material:PP/stainless steel ect.
2 Timely delivery
3 Manufacturer, factory
Performance index--- water filter element
- Material: PP, stainless steel, absorbent cotton fiber, Activated carbon, kapok fiber, polyester polypropylene
- precision: 1-70um;
- Working temperature: ≤90°C;
- Pressure: 20°C:0.34Mpa, 70°C:0.24Mpa;
- Flow:632-1890L/min;
- Efficiency: 99.99%.
Feature--- water filter element
- Set adsorption, filtration, intercept, catalysis in a body;
- Acid, alkali, salt and different kinds of organic solvent;
- Big flow, high filters efficiency, change convenience .etc;
- High filtrating precision, big flow, small differential pressure , high compression strength , big
- Quantity accept dirt . non-toxic, tasteless , non secondary pollution.
Advantages--- water filter element
- Stainless steel pleated filter element has low pressure drop due to high porosity;
- Easily cleanable and with long life-span;
- Under ISO9001-2000 quality certificate.
Work principle: (XLDM series)--- water filter element
- The filter medium of the water filter is polypropylene (XLD) what is exclusive filter material , It can be ensure be consistent in high efficient for folding ripple type. Fluid flowing from in to out , Pollutant is catch inside of filter element;
- The water filter element has many characteristics.
Application--- water filter element
Electric utility industry : pure water , condensate water filtering ; chemical industry ,
petrochemical industry : dissolvent , coating , magnetism liquid , detergent , liquid candle filtering ;
pharmaceutical industry : hospital water , pharmacy injection , traditional Chinese clothing liquid
filtering ;
Food industry : food , drink drinking water , liquor filtering.
Model and Size
Name |
Model |
Length |
Filtr. |
0D |
Temperature |
Flow (L/min) |
Press. |
Loss Pressure (Mpa) |
|
Initial |
Max |
||||||||
Big flow |
XLDM-20×* |
20 |
1~70 |
6 |
70 |
632 |
20°C:0.34 |
≤0.08 |
0.25 |
XLDM-40×* |
1260 |
||||||||
XLDM-60×* |
1890 |
||||||||
Name |
Model |
Length |
Filtr. |
0D |
ID |
Temperature |
Press. |
Loss pressure (Mpa) |
|
Initial |
Max |
||||||||
Melt&spurts |
RP-L×micron |
5~60 |
1~50 |
φ60 |
φ28 |
≤60 |
0.5 |
≤0.02 |
0.2 |
Name |
Model |
Length |
Filtr. |
0D |
ID |
Temperature |
Press. |
Loss pressure(Mpa) |
|
Initial |
Max |
||||||||
Yarn-wound |
CR-L×micron |
5~60 |
1~50 |
φ60 |
φ28 |
≤70 or ≤90 |
0.5 |
≤0.02 |
0.2 |
