DN20 Y type acid resistance pump strainer
- 10000 Piece / Pieces per Month
- Qingdao Shanghai Tianjin
- T/T
Product Details
Condition: | New | Type: | RO | Medium Material: | Active Carbon |
Place of Origin: | Henan, China | Brand Name: | D.King | Model Number: | FIR type |
Voltage: | water treatment | Power(W): | pump strainer | Dimension(L*W*H): | 300*640*950mm |
Weight: | 50KG | Certification: | ISO9001:2008 | Warranty: | 1 year |
After-sales Service Provided: | Overseas service center available |
Product Description
DN20 Y type acid resistance pump strainer
Material:stainless steel, carbon steel
DN20 Y type acid resistance pump strainer
property:Housing material : carbon steel , stainless steel
Nominal diameter : DN15-DN600 mm
Filter screen material : stainless steel
Sealing material : NBR , pllytef (according to working medium )
Working temperature : no more than 90 centigrade
Connection type : flange
Normal pressure : 1.6-10MPa
Micron rating : 10-480 mesh (water 18-30 mesh , gas 40-100 mesh , oil 100-480 mesh)
DN20 Y type acid resistance pump strainer
Introduction:Y type filter is belong to pipeline rude filter series .Normally installed in pressure reducing valve, pressure relief valve, the valve for water or other equipment inlet end .
effect:Used to clean up the impurity in the media, in order to protect the valve and the equipment normally use .
feature:easy made, advanced structure, easy install and washing, big accept dirt, small resistance, easy drain contamination.
DN20 Y type acid resistance pump strainer
Technical parameters
- Housing material : carbon steel , stainless steel
- Nominal diameter : DN15-DN600 mm
- Filter screen material : stainless steel
- Sealing material : NBR , pllytef (according to working medium )
- Working temperature : no more than 90 centigrade
- Connection type : flange
- Normal pressure : 1.6-10MPa
- Micron rating : 10-480 mesh (water 18-30 mesh , gas 40-100 mesh , oil 100-480 mesh)
DN20 Y type acid resistance pump strainer
Model and size
Model | Size (mm) | Valid filter area m2 | ||||
DN | In | L | H | H1 | ||
FIR-15×* | 15 | 1/2 | 125 | 70 | 150 | 0.00185 |
FIR-20×* | 20 | 3/4 | 145 | 70 | 150 | 0.00281 |
FIR-25×* | 25 | 1 | 160 | 80 | 160 | 0.00343 |
FIR-32×* | 32 | 1 1/4 | 180 | 90 | 180 | 0.00486 |
FIR-40×* | 40 | 1 1/2 | 200 | 100 | 240 | 0.00767 |
FIR-50×* | 50 | 2 | 220 | 130 | 250 | 0.01161 |
FIR-65×* | 65 | 2 1/2 | 260 | 165 | 350 | 0.02111 |
FIR-80×* | 80 | 3 | 280 | 195 | 390 | 0.03029 |
FIR-100×* | 100 | 4 | 320 | 230 | 450 | 0.04063 |
FIR-125×* | 125 | 5 | 320 | 230 | 490 | 0.05523 |
FIR-150×* | 150 | 6 | 380 | 335 | 580 | 0.07709 |
FIR-200×* | 200 | 8 | 495 | 420 | 690 | 0.11967 |
FIR-250×* | 250 | 10 | 595 | 500 | 800 | 0.19155 |
FIR-300×* | 300 | 12 | 640 | 580 | 950 | 0.26738 |
FIR-350×* | 350 | 14 | 750 | 650 | 1100 | 0.30926 |
FIR-400×* | 400 | 16 | 800 | 700 | 1360 | 0.40946 |
FIR-450×* | 450 | 18 | 850 | 800 | 1500 | 0.55638 |
FIR-500×* | 500 | 20 | 900 | 875 | 1650 | 0.65385 |
FIR-550×* | 550 | 22 | 1000 | 940 | 1780 | 0.76956 |
FIR-600×* | 600 | 24 | 1250 | 1050 | 1900 | 0.87528 |
DN20 Y type acid resistance pump strainer
About us
Xinxiang D.King Industry Co., Ltd. mainly produce complete range of filters, filter elements, filter machines and hydraulic accessories for fluid power industry.
It's located in "China filtration city Xinxiang". D.King has superior R & D team, professional technical team, experienced overseas sales team and perfect after-sales service system.
If you are interested in this product , pls sent the following questions to us , we will calculate the best to you with the specifications :
- size : OD , height
- material
- micron rating
- quantity
....
