Specifications
micron filter1.mainly used in oil filter
2.high intensity,without material from
3.high carrying capacity
4.ISO9001-2008
Introductions:
Candle type micron filter is mainly used in oil filter, by many filter cores and a magnetic cores, with size, effectively increase the filtering area. With metal wire network filter medium, pressure loss with small resistance, high strength, can be repeated washing flush, etc. Filter and USES threaded coupling bolts or, installation and removal, clean easily
Use scope:
Applicable in metallurgical, petrochemical, machinery manufacturing, paper making, textile, food and medicine, life, and environmental protection, oil, water filtration, involving all industries:
Crude oil, fuel oil, petrol, kerosene, diesel oil filter, etc
The hydraulic oil, lubricating oil, oil, gear oil filter .etc
Raw water, sewage , plain water ,reclaimed water filtration .etc
Main features:
- the high intensity, long service life, corrosion resistance, temperature range, without material from
- big filter area, big flow, porosity, permeability, high carrying capacity, with strong sex (can be repeated cleaning)
- with size, Z series (type filter) filtering area for Y series (cylindrical) filtering area of 2.5-4 times, prolong the cartridge replacement cycles
- installation ,removal and clean easily
Note : Single filter cores OD certain, length can be adjusted
Name | Model | Connection type | Nominal flow rate(L/min) | Filter precision(um) | Nominal pressure(MPa) | Pressure loss(MPa) | Size (mm) | ||
Initial | Max | D | L | ||||||
Candle filter element | BYLX-30×223 | M26×1.5 | 20 | 20 25 30 40 80 | 1.0 | No more than 0.1 | 0.35 | 30 | 223 |
BYLX-30×400 | 35 | 30 | 400 | ||||||
BYLX-30×440 | 40 | 30 | 440 | ||||||
BYLX-30×723 | 60 | 30 | 723 | ||||||
BYLX-30×245 | φ26 | 20 | 30 | 245 | |||||
BYLX-30×422 | 35 | 30 | 422 | ||||||
BYLX-30×462 | 40 | 30 | 462 | ||||||
BYLX-30×745 | 60 | 30 | 745 | ||||||
According to the demand of user can be listed in order of size parameters, the filter element
