Specifications
de filter1.mainly suitable for high temperature,high pressure,high viscosity polymer
2.high strength
3.ISO9001-2008
Introductions:
Melt filter mainly suitable for high temperature and high pressure, high viscosity polymer, polyester filtering. Filter for stainless steel (upper cover material, ensure the 316L) corrosion resistance, filter medium for stainless steel fiber felt or stainless steel centenary sintering, besides folding corrugated shape, small size, can be repeated filter area cleaning. Type sintering felt good air permeability, carrying capacity, long service life, screen type aperture, high strength, good workability, clean easily.
Use scope:
Petroleum, petrochemical industry, crude oil, high viscosity hydraulic oil filter, oil, asphalt
Chemical industry: polymer, polyester, ink filters
Chemical fiber and textile industry: polyester chip, short silk, filament in the production of polymer melt, and pre-polymer filtering
Main features:
1. high-temperature high-pressure, long life, corrosion resistance is strong, such as material from
2 .big filter area, big flow, porosity, permeability, high carrying capacity, the initial low differential pressure, can be repeated washing
Name | Model | Connection mode | Working medium | Filtration precision(um) | Working temperature(°C) | Pressure (MPa) | Pressure loss(MPa) | |
Initial | max | |||||||
Melt filter | RLX-35×207 | 3/4-16UNF 3/4-10UNF M20×1.5 M30×1.5 M33×1.5 | Fluid viscosity no more than 260 Pa. | Fining felt 5-60 Wire netting 10-100 | No more than 300 | 32 | No more than 0.1 | 6.8 |
RLX-35×248 | ||||||||
RLX-35×424 | ||||||||
RLX-50×485 | ||||||||
RLX-50×207 | ||||||||
RLX-50×500 | ||||||||
RLX-50×870 | ||||||||
RLX-60×548 | ||||||||
RLX-60×798 | ||||||||
RLX-60×1048 | ||||||||
