Specifications
1.FTP Cat5e RJ45 Connector RJ45 cable2.24AWG*4P,copper
3.RJ45,8P8C
4.PVC molding
RJ45 Connector
FTP Cat5e RJ45 Connector RJ45 cable
Specification:
1.CAT5E UTP and FTP Patch cable
2.with RJ45 8P8C connector
3.Rated Temperature:75Degree
4. Solid/Strands Cores are available
5. Standard:UL444,TIA/EIA568B.2,YD/T1019-2001
6. 24AWG*4P, 23AWG*4P, OD:5.5mm-6.0mm
7. Insulation :HDPE,
8. Jacket: PVC
9. Rip cord: Per your request
FTP Cat5e RJ45 Connector RJ45 cable
Products Description:
Constructed of High-Performance Cat 5E cable suitable for 1000MHZ High-speed data applications, gigabit ethernet, fast ethernet, 155Mbps TP-PMD/CDDI . Boots offer cable-end color ID, strain relief and RJ45 plug tab protection from snagging on cables or connectors when routing in ceiling and under floors, suitable for indoor installations.
Electrical Characteristic:
1.1.0-100.0MHz Impedance (ohms):100 +/- 15
2.1.0-350.0MHz Delay Skew (ns/100m):<=45
3.Pair-to-Ground Capacitance Unbalance (pF/100m):<=330
4.Max. Conductor DC Resistance 20 degree(ohms/km):93.8
5.Resistance Unbalance (%):<=5
Application: 100 Base-TX, 100VG-AnyLAN, 1000Base-T, ATM, Noisy Environment
Remark: 250MHz 550MHz ATM 155Mbps, 100mbps TPDDI, Fast Ether-net etc.
FTP Cat5e RJ45 to RJ45 Ethernet Lan cable
