AWM 2835 FTP Lan Cable High Speed Factory Price
Specifications:
• Conductor: bare copper wire O0.51 ± 0.01 mm, 24 AWG
• Insulation: High density polyethylene, minimum thickness of 0.18 mm
• Conductor diameter 0.9 ± 0.02 mm
• 4 twisted pairs are covered with PVC jacket (minimum thickness of the shell 0.4 mm)
• The external cable diameter of 5.1 ± 0.2 mm
• Standard packing: 18.5 x 37.5 x 36.5 cm (W x H x D) - 305 m
• Weight without cable, weight: 9.7 kg
• Cable Weight with packaging: 10.5 kg
• Weight 1 km of cable: 31.8 kg
• Operating temperature: -20 ° C - +75 ° C
• Standards: UL444/UL1581, TIA / EIA 568B.2
Conductor resistance at 20 ° C 9.38 Om/100 m
DC Resistance Unbalance 5%
Capacitive unbalance pair to ground 330 pF/100m
Impedance 0.772-100 MHz 85-115 Ohm
Maximum working capacity of 5.6 nF / m
Features:
1.Name: 4-pair FTP Cat5e cable
2.This kind of cable use bare copper to be the center conduction with the specification 24AWG and PE to be the dielectric
3.The jacket is made of fireproof material, which is so meaningful to the Cat5e communication
4.This Cat.5e FTP cable is conform to the ISO/IEC, TIA/EIA, and EN standards and the electrical characteristics are exceed the latest Cat5e standards
5.LSZH (low smoke zero halogen), which is the symbol of environmental protection.
Electric performance:
1) Round resistance (at 20°C): 160Ω/km
2) Capacitance: 42PF/m
3) Impedance: 100Ω±15Ω
4) Transmission impedance: (1/10/30MH2: <45/90/190mΩ
5) Defer warp: 9ns/100m
6) NVP: 76%
Environment condition:
1) Halogen content: FRNC/LSOH, according to IEC 60754-2
2) Mist density: according to IEC 61034
3) Flammability grade: according to IEC 60332-1
Application:
1) Data transmission cable for structure laying electric wires
2) For figure, voice, data and video signal transmission
3) Suitable for all of D-level lines and Cat.5e application
4) ISDN, 10M Ethernet, 100M speed Ethernet, KM Ethernet, 4/16Mbit/s Token-Ring, TP-PMD/TP-DDI 125Mbit/s, ATM 155Mbit/s
Product Photo:
Certificate Photo:
Factory Photo:
