UL SPT-3 16awg Flexible Power Cords
US$ 0.1 - 99
/ Meter
6100 Meters(Min. Order)
- Shanghai port
- T/T
You May Like
-
UL SPT-3 12awg PVC Flexible Power Cords
-
UL SPT-2 16awg Flexible Power Cords
-
UL SPT-3 14awg PVC Flexible Power Cords
-
UL1007 PVC Insulated 300V 18 Awg Single Solid Copper Wire
-
26AWG 7/0.16mm Pvc Insulated 300V UL 1007 Wire
-
UL1007 80 Centigrade 300V Tinned Copper Conductor Heat-resistant Electrical Wire
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Winpower | |
| Model Number | UL STP-3 16awg 26/0.254mm | Type | Insulated | |
| Application | Other, power supply cord | Conductor Material | Copper | |
| Conductor Type | Stranded | Insulation Material | PVC |
Product Description
UL SPT-3 16awg Flexible Power Cords
Specification: 20awg 26/0.16mm
Rated temperature:60℃
Rated voltage:300V
Reference standard:UL62,UL1581, CSA C22.2No.49
Stranded ,tinned or bare copper conductor 20~18AWG
PVC insulation , comply with RoHS environmental standard
PVC jacket , comply with RoHS environmental standard
Passes UL VW-1,CSA FT2 and JQA -F-Mark flame test
Uniform insulation thickness to ensure easy stripping and cutting
For general purpose use for power supply cord
| CONDUCTOR | GROUNG -ING | INSULATION | MAX.COND. RESISTANCE (Ω/km,20℃,DC) | ||||||
| AWG | CONSTRUCTION (NO./MM) | DIA (mm) | NO. | O.D. (mm) | INSULATION THICKNESS (mm) | O.D (mm) | |||
| 18 | 41/0.16 | 1.18 | 2 | — | 1.52 | 4.30*8.60 | 22.4 | ||
| 3 | 2.00 | 1.52 | 4.30*11.00 | ||||||
| 16 | 26/0.254 | 1.49 | 2 | — | 1.52 | 4.60*9.20 | 14.1 | ||
| 3 | 2.40 | 1.52 | 4.60*12.30 | ||||||
| 14 | 41/0.254 | 1.88 | 2 | — | 2.03 | 7.20*14.40 | 8.88 | ||
| 12 | 65/0.254 | 2.36 | 2 | — | 2.41 | 7.20*14.40 | 5.58 | ||
