ultrafiltration membrane pilot for waste water treatment

Specifications

ultrafiltration membrane pilot for wastewater treatment
MF/UF/NF ceramic membrane
Raw material: 99% -Al2O3/ ZrO2

ultrafiltration membrane pilot for waste water treatment



1:Components:

Membrane module,housing,feed tank,centrifugal pump,flow/pressure/temperature meter, back flush tank,electric  panel,valves and pipes;



2:Properties:

Material : Zirconia,Alumina,Titania ;

Pore size of membrane: 10nm,20nm,30nm,50nm;

                     0.1um,0.2um,0.5um,0.8um,1.2um,1.5um;

Pressure resistance:     1.0Mpa

pH range:             0-14



3:Backflushing: Automatic backflushing;



4:Specification of membranes:







5:Applications:

Separation of liquids and solids;separation of oil and water;separation of liquids and liquids;

(especially for filtration of food and beverage industries,chemcical and petrochemical industries,

pharmaceutical and mining industries.)



Typical Applications:
1) Biochemical and Pharmaceutical Industries: Clarification and purification of the fermentation products as well as purification or separation of product slurries;
2) Environmental applications: Waste Water clarification and separation;
3) Food and Beverage Industry: Microfiltration of milk, clarification of fruit juice and separation of soyabean protein;
4) Highly useful for various filtration applications in the Petro-Chemical Industry;
5) Other fields: Reclamation of nano powders, filtration of acid/alkali containing liquids.
