Help CenterPrimary-efficient Filter
Related Products
Specifications
1)Framed primary-efficient filter,Air material2)General air conditioning systems
3)Large dust holding capacity
Cardboard disposable filter
It mainly filters the particles with diameters of over 5 micron, the frame is made of hard anti-flame paper boards or aluminum and it was combined with synthetic glass fiber or glass fiber, the filter can be flat or folded, the cost is much lower, resistance is small, the dust capacity is large, it is changed easily. The filtration grade is G2,G3,G4, it is used widely for primary filtration.
|
Filter Class |
Dimensions W*H*D mm |
Rated Airflow m3/h |
Average Arrestance |
Initial Resistance(pa) |
Recommended Final Resistance(pa) |
Continuous Temperature(°C) |
Frame |
G3 |
595*595*46 |
3200 |
85% |
35 |
180 |
80 |
Waterproofing chipboard
Aluminum alloy
Galvanized sheet |
595*495*46 |
2700 |
||||||
595*295*46 |
1600 |
||||||
495*495*46 |
2200 |
||||||
G4 |
595*595*46 |
3200 |
90% |
45 |
200 |
80 |
|
595*495*46 |
2700 |
||||||
595*295*46 |
1600 |
||||||
495*495*46 |
2200 |
Note: Other specifications are available on request
