Help CenterCardboard Air Filter
Related Products
Specifications
1. cardboard Panel pre Filter2. Economical.
3. disposed and easy to handle
4. no contamination to the environment
Cardboard Filter
It mainly filters the particles with diameters of over 5 micron, the frame is made of hard anti-flame paper boards or aluminum and it was combined with synthetic glass fiber or glass fiber, the filter can be flat or folded, the cost is much lower, resistance is small, the dust capacity is large, it is changed easily. The filtration grade is G2,G3,G4, it is used widely for primary filtration.
Collect 5 micron and larger particles
Low initial resistance
High air flow
Completely disposable
Large dust holding capacity
Efficiency: 90%
Maximum working temperature is 80OC
|
Filter Class |
Dimensions W*H*D mm |
Rated Airflow m3/h |
Average Arrestance |
Initial Resistance(pa) |
Recommended Final Resistance(pa) |
Continuous Temperature(°C) |
Frame |
G3 |
595*595*46 |
3200 |
85% |
35 |
180 |
80 |
Waterproofing chipboard
Aluminum alloy
Galvanized sheet |
595*495*46 |
2700 |
||||||
595*295*46 |
1600 |
||||||
495*495*46 |
2200 |
||||||
G4 |
595*595*46 |
3200 |
90% |
45 |
200 |
80 |
|
595*495*46 |
2700 |
||||||
595*295*46 |
1600 |
||||||
495*495*46 |
2200 |
Note: Other specifications are available on request
