Home > Products > Foam Concrete Pump > Light Weight Concrete Pump
Light Weight Concrete Pump
- QINGDAO
- T/T Money Gram
You May Like
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | SYM | |
| Model Number | SYT-30 | Power(W) | 30kw | |
| Weight | 1900kg | Dimension(L*W*H) | 3100*920*1300 mm | |
| Warranty | 12months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1- Hydraulic drive;2- Reasonable design;
3- Reliable performance
SYT-30 conveying pump for light weight foam concrete
Introduction:
Conveying pump adopts hydraulic drive, with reasonable design, reliable performance, easy operation, convenient and flexible, economic and durable, high efficiency and low consumption, enjoys high reputation in domestic market..
Main Technical Data:
ITEM | DATA |
Max. theoretical grouting flow | 30 m³/h |
Max. theoretical conveying pressure | 8 Mpa |
Max. theoretical horizontal transporting range | 600 m |
Max. theoretical vertical transporting height | 200 m |
Max. particle size of aggregates | 8 mm |
Pump head quantity | 2 Pcs |
Oil cylinder (material cylinder) quantity | 2 Pcs |
Oil cylinder inside diameter*stroke | Φ80*1000 mm |
Material cylinder inside diameter*stroke | Φ140*1000 mm |
Max. pressure of hydraulic system | 24 Mpa |
Oil pressure box volume | 200L |
Motor power | 30 KW |
Dimension (L*W*H) | 3100*920*1300 mm |
Weight (whole machine) | 1900 kg |
