Contact Platform Support
Help CenterHoist
US$ 37,600 - 44,600
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
feitianhong
Model Number:
SC200/200
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SMZ150-1 Self-propelled Jack Gantry LiftNegotiableMOQ: 1 Set -
Building Hoist Used for Passenger and Material LiftingNegotiableMOQ: 1 Set
-
External Passenger Elevator for BuildingsNegotiableMOQ: 1 Set
-
Hoist Lifting MachineNegotiableMOQ: 1 Set
-
Suspension Scaffold for Sale/mini Electric Wire Rope Hoist ZLP500/630/800NegotiableMOQ: 1 Set
Place of Origin
Beijing, China
Brand Name
feitianhong
Model Number
SC200/200
Usage
Construction Hoist
Power Source
Electric
Sling Type
Wire Rope
Maximum Lifting Weight
2000kg
Maximum Lifting Height
200m
Lift Speed
28-38m/min
Specifications
hoistbuilding hoist
used for lifting concret, people and other materials in construction industry
hoist
building hoist
lifting capacity: 1-2 tons.
running speed: 28-38m/min
starting current: 270A
working current: 70A
product features:
its highly safety equipped with lifting weight limiter and preventing fall device.
standard knot is with anti-corrosion treatment for the internal and external wall.
Technical parameter of SC200/200 construction elevator
| Item | Unit | Parameter | Notes |
| Rated loading capacity | kg | 2000/2000 | |
| Rated lifting speed | m/min | 33 | |
| Max. lifting height | m | 150 | |
| Inside dimension of cage | m | 3*1.5*2.5 | |
| Motor model | yzz132m-4 | ||
| Starting current | A | 270 | |
| Working current | A | 70 | |
| Motor power | KW | 2*3*11 | |
| Motor rotational speed | h/min | 1480 | |
| Guide rail bracket dimension | m | 0.65*0.65 | |
| Guide rail bracket weight | kg | 148 | |
| Overall dimension | m | 5.3*3.4 | |
| Total weight | t | 20 | h=150m |
