Specifications
1) 27 years professional manufacturer2) Public Company in 2010
3) Three plants to produce
4) Turnover:400 Million
Fire-resisting PVC Insulated Electrical Cable with Rated Voltage of 450/750V and below
1.Application:
This product is mainly designed for power equipment,instrument and
telecommunication device with rated AC voltage of 450/750V and below.
1.1. Electrical performance (at 250MHz):
1.0 to 100.0MHz impedance: 100 ± 15 ohms
100.0 to 250.0MHz impedance: 100 ± 22 ohms
Impedance delay screw (ns/100m): <45
Pair to ground capacitance unbalance: (PF/100m) 330 maximum
Conductor DC resistance: 20% <73.2 ohms/km
Resistance unbalance: 5%
Test object: Jacket
Test material: PVC & LSZH
Tensile strength: ≥ 13.8MPa
Aging elongation: ≥ 100%
Aging condition: 100 x 240
After tensile strength: ≥ 85% MPA of unaged
Aging elongation: ≥ 50% of aged
Cold bend (-20 ± 2° C x 4hrs): No crock
Specification
N-BV |
PVC-insulated fire-resisting cable(wire) |
N-BV V |
PVC-insulated and sheathed fire-resisting cable(wire) |
N-V V |
PVC-insulated and sheathed fire-resisting power cable(wire) |
N-V V22 |
PVC-insulated,steel tape armored,PVC-sheathed fire-resisting power cable |
N-VV32 |
PVC-insulated,fine steel wire armored,PVC-sheathed fire-resisting power cable |
N-YJV |
XLPE-insulated and PVC sheathed fire-resisting power cable |
N-YJV22 |
XLPE insulated, steel tape armored, PVC sheathed fire-resisting power cable |
N-YJV32 |
XLPE insulated, fine steel wire armored, PVC sheathed fire-resisting power cable |
N-YJY |
XLPE insulated and PE (polyolefin) sheathed fire-resisting power cable |
N-YJY23 |
XLPE insulated, steel tape armored, PE (polyolefin) sheathed fire-resisting power cable |
N-YJY33 |
XLPE insulated, fine steel wire armored, PE (polyolefin) sheathed fire-resisting power cable |
N-KVV |
PVC insulated and PVC sheathed fire-resisting control cable |
N-KVV22 |
PVC insulated, steel tape armored, PVC sheathed fire-resisting control cable |
N-KVV32 |
PVC insulated, fine steel wire armored, PVC sheathed fire-resisting control cable |
N-KVVP2-22 |
PVC insulated, copper tape collectively screened, steel tape armored and PVC sheathed fire-resisting control cable |
N-KYY |
PE insulated and PE sheathed fire-resisting control cable |
N-KYJY |
XLPE insulated and PE (polyolefin) sheathed fire-resisting control cable |
N-KYJY23 |
XLPE insulated, steel tape armored, PE (polyolefin) sheathed fire-resisting control cable |
N-RV |
PVC insulated fire-resisting flexible cable |
N-KYY |
PE insulated and PE sheathed fire-resisting control cable |
N-KYJY |
XLPE insulated and PE (polyolefin) sheathed fire-resisting control cable |
N-KYJY23 |
XLPE insulated, steel tape armored, PE (polyolefin) sheathed fire-resisting control cable |
N-RV |
PVC insulated fire-resisting flexible cable |
VV(VLV) |
Copper(aluminum) core PVC insulated and PVC sheathed power cable |
VY(VLY) |
Copper(aluminum) core PVC insulated and PE sheathed power cable |
VV22(VLV22) |
Copper(aluminum) core PVC insulated,steel tape armored and PVC sheathed power cable |
VV23(VLV23) |
Copper(aluminum) core PVC insulated ,steel tape armored and PE sheathed power cable |
|
Core Number |
Colour |
||
Main Core |
The fourth and fifth core |
||
1 |
Any(Black first) |
|
|
2 |
Red,Light blue |
|
|
3 |
Red,Yellow,Green |
|
|
4,3+1 |
Red,Yellow,Green |
Light blue |
|
4+1,3+2 |
Red,Yellow,Green |
Light blue |
Black |
Quality Managements
(1) Lab Overview
(1) Certificates
Company Profile
TONGDING GROUP,located in the Cable Industry Basement—Wujiang,in the
boundary of Jiangsu,Zhejiang and Shanghai,is an outstanding private group with a
wide range of business including optical and electric cables,communication
equipments,cable materials,real estate,finance,etc
1986-2012,in 26 years,we have been listed on:
Top500 Private Business of China
Top500 Competitiveness of China
Top500 Manufacturers of China
Top500 Most Valuable Brands of China
"TDGD" China Well-Known Trademark
JIANGSU TONGDING OPTICAL-ELECTRONIC CO.,LTD, is a subsidiary
of TONGDING GROUP. We focus on:
♦ Optical Fiber Cable (14,000,000 Fiber Kms )
♦ Communication Telephone Cable (4,320,000 Kms)
♦ Networking Cable (1,000,000 Boxes )
♦ Feeder Cable/RF Coaxial Cable (40,000 Kms)
♦ Electric/Power Cable with Low-voltage(300V,450V,600V,0.6/1 KV)
♦ Passive Optical Network Equipments
♦ Special Cable(OPLC,Optical Cable+Power Cable,Perfect Solution for The Last
Mile)
♦ Railway Signal Cable
In 2010,we succeed to be listed in mainland China (Stock Code:002491)
Waiting for your purchasing.
Skype:andygu87
The pursuit of providing high-quality product and service never stops.
