Home > Instruments & Meters > Test Instrument > Test Machine > P6010A(100MHz,10KV) Digital Oscilloscope High Voltage Probe
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Pintech
Model Number:
P6010A
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HVP-40DM(400V/4KV/40KV) DC High Voltage Meter/LCD MeterNegotiableMOQ: 1 Set -
HVP-15HF (40MHz ,0~10 KV:1000:1)high Voltage Testing ProbeNegotiableMOQ: 1 Set
-
Free Delivery HVP-40(specially for DMM,0~40KV)digital Multimeter High Voltage ProbeNegotiableMOQ: 1 Set
-
Free Delivery P6039A(220MHz,40KV)Tektronix P6015A High Voltage ProbeNegotiableMOQ: 1 Set
-
Free Delivery P6008 (8KV/40MHz)high Voltage Measuring InstrumentNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
Pintech
Model Number
P6010A
Power
Electronic
Usage
Other, eletronic power testing
Product Description
Model | P6010A High Voltage Probe |
Division Ratio | 100:1 |
Read Out | |
Input Resistance | 100MΩ |
Input Capacitor | 2.0 PF |
Max. DC+AC pack | 10KV CAT |
Max. AC RMS. | 7KV CAT |
Max. Loading Current | 100uA |
Band Width | DC~120MHz |
Rise Time | 3.0 ns |
Signal /Noise | >60dB at 1KHz; >50dB at 1MHz |
DCV Accuracy | 3% Full Range |
ACV Accuracy | 3% at 1KHz |
Temp. Coefficient | 200 PPM/ |
Compensation Range | 10PF~35PF |
Safety | Meets EN61010-031CAT |
Cable Length | 2M±0.2M |
Operation Temp. | -10~55 |
Humidity | 85%RH or less(at 35) |
Storage Temp. | -20~70 |
Color: Handel/Body | Black/Milk Gray |
Weight /Volume | 460g/80(W)×80(H) ×320(L)mm |
